SDO HMI 2011-11-23 06:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 10.63 | 74.31 | 19.42 | 137.93 | 19.09 | 193.71 | -74.11 | 70.70 | 0.9642 | -258.8 | -101.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-11-23 06:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 7.80 | 72.00 | 14.17 | 132.99 | 19.06 | 193.87 | -73.94 | 70.72 | 0.9635 | -506.6 | -117.2 | |
| 2.83 | -1.00 | 5.25 | -1.00 | 19.11 | 193.58 | -74.24 | 70.68 | 0.9648 | 170.8 | 999999 | |
| 0.00 | 1.71 | 0.00 | 3.40 | 18.76 | 192.44 | -75.37 | 71.10 | 0.9695 | 418.0 | 255.2 | |
| 0.00 | 0.60 | 0.00 | 1.54 | 20.87 | 189.08 | -78.73 | 69.10 | 0.9818 | 322.0 | 297.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
