SDO HMI 2011-11-23 19:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 80.84 | 504.01 | 47.03 | 293.01 | 15.05 | 231.79 | -28.89 | 63.37 | 0.5223 | -455.1 | -222.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-11-23 19:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 9.59 | 45.64 | 5.37 | 25.49 | 13.08 | 235.05 | -25.63 | 64.86 | 0.4673 | -1033.3 | -402.1 | |
| 0.00 | 1.20 | 0.00 | 0.69 | 17.54 | 234.00 | -26.67 | 57.40 | 0.5101 | -845.0 | -641.1 | |
| 0.00 | 1.46 | 0.00 | 0.84 | 17.73 | 233.97 | -26.70 | 57.11 | 0.5118 | -807.0 | -675.2 | |
| 38.79 | 271.27 | 21.98 | 153.67 | 14.79 | 234.30 | -26.38 | 62.13 | 0.4879 | -1301.2 | -488.1 | |
| 5.48 | 5.99 | 3.09 | 3.38 | 13.22 | 234.36 | -26.32 | 65.10 | 0.4778 | -933.5 | -673.3 | |
| 0.00 | 2.57 | 0.00 | 1.48 | 17.66 | 233.56 | -27.11 | 57.58 | 0.5165 | -742.0 | -568.1 | |
| 0.00 | 1.37 | 0.00 | 0.79 | 17.41 | 233.47 | -27.21 | 58.09 | 0.5160 | -813.0 | -637.4 | |
| 0.00 | 1.11 | 0.00 | 0.63 | 11.98 | 234.09 | -26.59 | 67.75 | 0.4750 | 750.0 | 535.1 | |
| 0.00 | 1.46 | 0.00 | 0.84 | 17.22 | 233.25 | -27.42 | 58.60 | 0.5175 | -704.0 | -513.9 | |
| 0.00 | 1.37 | 0.00 | 0.77 | 12.70 | 233.84 | -26.84 | 66.49 | 0.4822 | -694.0 | -510.6 | |
| 1.46 | 2.14 | 0.83 | 1.21 | 12.84 | 233.45 | -27.23 | 66.48 | 0.4885 | -584.8 | -210.0 | |
| 0.00 | 2.14 | 0.00 | 1.23 | 14.77 | 232.96 | -27.72 | 63.20 | 0.5059 | -695.0 | -425.6 | |
| 0.00 | 0.86 | 0.00 | 0.50 | 17.02 | 232.16 | -28.51 | 59.82 | 0.5302 | -752.0 | -666.0 | |
| 0.00 | 0.86 | 0.00 | 0.49 | 11.72 | 232.76 | -27.92 | 69.11 | 0.4928 | 784.0 | 697.8 | |
| 0.00 | 1.11 | 0.00 | 0.64 | 14.55 | 232.40 | -28.28 | 64.00 | 0.5122 | -783.0 | -603.2 | |
| 0.00 | 1.11 | 0.00 | 0.64 | 12.80 | 232.60 | -28.08 | 67.13 | 0.5002 | 1012.0 | 774.8 | |
| 0.00 | 0.69 | 0.00 | 0.39 | 11.75 | 232.58 | -28.09 | 69.16 | 0.4954 | 789.0 | 640.6 | |
| 0.00 | 1.03 | 0.00 | 0.60 | 17.39 | 231.75 | -28.93 | 59.53 | 0.5378 | -774.0 | -587.8 | |
| 0.00 | 0.43 | 0.00 | 0.25 | 17.54 | 231.58 | -29.10 | 59.40 | 0.5409 | -582.0 | -482.2 | |
| 0.00 | 3.51 | 0.00 | 2.07 | 17.75 | 231.36 | -29.32 | 59.21 | 0.5450 | -669.0 | -543.0 | |
| 0.00 | 0.94 | 0.00 | 0.54 | 13.72 | 231.61 | -29.07 | 66.05 | 0.5185 | -585.0 | -432.7 | |
| 0.00 | 2.74 | 0.00 | 1.61 | 15.75 | 231.06 | -29.61 | 62.81 | 0.5368 | -755.0 | -623.0 | |
| 2.14 | 14.04 | 1.26 | 8.26 | 15.71 | 230.50 | -30.18 | 63.26 | 0.5440 | -708.3 | -668.4 | |
| 0.00 | 0.60 | 0.00 | 0.36 | 16.55 | 229.10 | -31.58 | 62.78 | 0.5667 | -565.0 | -407.0 | |
| 0.00 | 1.11 | 0.00 | 0.67 | 16.94 | 228.70 | -31.98 | 62.39 | 0.5740 | -775.0 | -625.1 | |
| 0.00 | 0.69 | 0.00 | 0.42 | 16.44 | 227.95 | -32.73 | 63.66 | 0.5808 | -511.0 | -443.8 | |
| 0.00 | 2.57 | 0.00 | 1.56 | 16.59 | 227.77 | -32.90 | 63.52 | 0.5838 | -608.0 | -503.6 | |
| 2.14 | 11.39 | 1.31 | 6.98 | 16.89 | 227.57 | -33.11 | 63.16 | 0.5880 | -649.4 | 126.5 | |
| 0.00 | 4.28 | 0.00 | 2.65 | 17.28 | 226.78 | -33.90 | 63.01 | 0.5999 | -533.0 | -445.3 | |
| 0.00 | 0.77 | 0.00 | 0.49 | 20.68 | 225.82 | -34.85 | 58.47 | 0.6296 | -541.0 | -451.7 | |
| 1.20 | 19.95 | 0.74 | 12.23 | 15.53 | 226.68 | -34.00 | 65.83 | 0.5927 | 928.9 | 339.4 | |
| 0.00 | 1.71 | 0.00 | 1.06 | 16.56 | 226.37 | -34.31 | 64.36 | 0.6016 | 752.0 | 618.9 | |
| 5.99 | 91.02 | 3.70 | 56.55 | 15.58 | 226.22 | -34.45 | 65.99 | 0.5988 | 916.9 | 557.7 | |
| 1.80 | -33.00 | 1.12 | -33.00 | 16.58 | 225.57 | -35.10 | 64.76 | 0.6116 | 924.4 | 999999 | |
| 11.05 | -33.00 | 6.88 | -33.00 | 16.00 | 225.65 | -35.02 | 65.62 | 0.6079 | 934.4 | 999999 | |
| 0.00 | 1.88 | 0.00 | 1.16 | 14.18 | 225.96 | -34.72 | 68.37 | 0.5963 | 529.0 | 399.4 | |
| 1.20 | -33.00 | 0.75 | -33.00 | 15.63 | 225.61 | -35.06 | 66.22 | 0.6068 | 614.5 | 999999 | |
| 0.00 | 1.03 | 0.00 | 0.64 | 16.76 | 225.31 | -35.37 | 64.62 | 0.6158 | 574.0 | 461.3 | |
| 0.00 | 0.94 | 0.00 | 0.59 | 14.74 | 225.33 | -35.34 | 67.75 | 0.6067 | 593.0 | 543.2 | |
| 0.00 | 1.03 | 0.00 | 0.64 | 14.65 | 225.16 | -35.51 | 67.98 | 0.6085 | 606.0 | 491.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
