SDO HMI 2011-11-24 10:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 23.81 | 73.41 | 27.01 | 83.36 | 18.79 | 315.67 | 63.22 | 290.11 | 0.9010 | -201.2 | -158.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-11-24 10:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 10.36 | 36.40 | 12.66 | 44.28 | 18.74 | 317.73 | 65.28 | 289.76 | 0.9158 | -567.4 | -310.1 | |
| 1.80 | 5.74 | 2.10 | 6.73 | 17.84 | 316.65 | 64.20 | 288.90 | 0.9077 | -643.1 | -457.2 | |
| 0.00 | 1.11 | 0.00 | 1.19 | 17.57 | 313.87 | 61.42 | 288.97 | 0.8872 | 289.0 | 223.6 | |
| 5.82 | 8.05 | 6.37 | 8.81 | 19.20 | 314.49 | 62.04 | 290.70 | 0.8936 | -528.0 | -244.2 | |
| 0.00 | 1.46 | 0.00 | 1.54 | 18.69 | 313.57 | 61.12 | 290.27 | 0.8861 | -390.0 | -342.8 | |
| 0.00 | 1.20 | 0.00 | 1.23 | 18.72 | 312.55 | 60.10 | 290.46 | 0.8784 | 185.0 | 163.5 | |
| 0.43 | 2.57 | 0.43 | 2.58 | 18.08 | 311.81 | 59.36 | 289.86 | 0.8717 | 441.2 | 254.8 | |
| 5.40 | 13.87 | 5.45 | 14.07 | 19.36 | 311.81 | 59.36 | 291.31 | 0.8733 | 533.5 | 216.1 | |
| 0.00 | 0.69 | 0.00 | 0.67 | 18.89 | 310.86 | 58.41 | 290.94 | 0.8650 | 378.0 | 341.6 | |
| 0.00 | 0.69 | 0.00 | 0.66 | 18.52 | 310.54 | 58.09 | 290.58 | 0.8618 | 471.0 | 356.6 | |
| 0.00 | 1.63 | 0.00 | 1.60 | 19.29 | 310.85 | 58.40 | 291.40 | 0.8655 | 582.0 | 499.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
