SDO HMI 2011-11-24 14:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 2.31 | 9.76 | 1.46 | 6.23 | 18.03 | 214.08 | -36.18 | 63.00 | 0.6327 | 326.4 | 402.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-11-24 14:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.77 | 0.00 | 0.49 | 20.74 | 215.47 | -34.79 | 58.21 | 0.6300 | 577.0 | 530.2 | |
| 0.00 | 0.86 | 0.00 | 0.54 | 20.36 | 215.38 | -34.88 | 58.82 | 0.6290 | 641.0 | 585.9 | |
| 2.31 | 3.08 | 1.46 | 1.95 | 17.65 | 214.54 | -35.71 | 63.32 | 0.6248 | -581.5 | -416.2 | |
| 0.00 | 0.86 | 0.00 | 0.56 | 20.37 | 213.58 | -36.67 | 59.87 | 0.6497 | 612.0 | 468.3 | |
| 0.00 | 0.51 | 0.00 | 0.33 | 17.72 | 213.64 | -36.62 | 63.68 | 0.6362 | 499.0 | 520.0 | |
| 0.00 | 1.37 | 0.00 | 0.87 | 15.79 | 213.92 | -36.34 | 66.45 | 0.6243 | 548.0 | 501.0 | |
| 0.00 | 2.31 | 0.00 | 1.49 | 17.28 | 212.93 | -37.33 | 64.69 | 0.6428 | 407.0 | 453.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
