SDO HMI 2011-11-24 17:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 8.99 | 59.75 | 4.97 | 32.75 | -16.17 | 266.70 | 18.10 | 224.19 | 0.4311 | 344.5 | 246.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-11-24 17:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.88 | 0.00 | 1.06 | -15.80 | 271.48 | 22.88 | 231.36 | 0.4810 | 817.0 | 696.2 | |
| 0.00 | 1.37 | 0.00 | 0.75 | -12.18 | 269.31 | 20.71 | 235.38 | 0.4219 | 842.0 | 669.8 | |
| 0.00 | 1.54 | 0.00 | 0.84 | -12.39 | 268.62 | 20.02 | 234.08 | 0.4147 | 815.0 | 661.1 | |
| 0.00 | 2.40 | 0.00 | 1.30 | -12.69 | 268.00 | 19.40 | 232.64 | 0.4094 | 757.0 | 641.9 | |
| 0.00 | 2.23 | 0.00 | 1.20 | -12.29 | 267.90 | 19.30 | 233.31 | 0.4045 | 960.0 | 736.7 | |
| 0.00 | 1.28 | 0.00 | 0.69 | -12.35 | 267.59 | 18.99 | 232.74 | 0.4010 | 961.0 | 808.5 | |
| 0.00 | 1.28 | 0.00 | 0.70 | -13.60 | 267.46 | 18.86 | 230.08 | 0.4114 | 697.0 | 509.6 | |
| 6.08 | 28.07 | 3.36 | 15.53 | -16.73 | 267.72 | 19.12 | 224.88 | 0.4465 | 1043.6 | 592.9 | |
| 2.91 | -8.00 | 1.61 | -8.00 | -17.04 | 267.72 | 19.12 | 224.36 | 0.4498 | 922.9 | 999999 | |
| 0.00 | 0.94 | 0.00 | 0.51 | -14.86 | 267.22 | 18.61 | 227.36 | 0.4212 | 833.0 | 666.3 | |
| 0.00 | 1.63 | 0.00 | 0.88 | -15.56 | 266.08 | 17.48 | 224.36 | 0.4157 | 923.0 | 739.8 | |
| 0.00 | 2.48 | 0.00 | 1.36 | -16.52 | 265.85 | 17.25 | 222.34 | 0.4239 | -962.0 | -797.4 | |
| 0.00 | 2.40 | 0.00 | 1.32 | -18.86 | 264.91 | 16.31 | 217.15 | 0.4418 | 762.0 | 604.5 | |
| 0.00 | 1.28 | 0.00 | 0.70 | -17.57 | 264.75 | 16.15 | 218.82 | 0.4248 | -898.0 | -812.3 | |
| 0.00 | 1.46 | 0.00 | 0.79 | -17.45 | 264.61 | 16.01 | 218.78 | 0.4218 | -998.0 | -857.2 | |
| 0.00 | 1.80 | 0.00 | 0.98 | -17.41 | 264.35 | 15.75 | 218.38 | 0.4189 | -939.0 | -749.0 | |
| 0.00 | 2.74 | 0.00 | 1.47 | -15.69 | 263.66 | 15.06 | 219.96 | 0.3912 | -497.0 | -504.3 | |
| 0.00 | 1.03 | 0.00 | 0.55 | -15.75 | 263.00 | 14.40 | 218.62 | 0.3851 | -840.0 | -689.0 | |
| 0.00 | 3.94 | 0.00 | 2.12 | -18.48 | 260.46 | 11.86 | 209.47 | 0.3980 | -656.0 | -686.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
