SDO HMI 2011-11-25 17:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 15.91 | 88.72 | 13.23 | 73.03 | -23.83 | 283.29 | 47.87 | 238.13 | 0.8007 | 454.4 | 247.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-11-25 17:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 11.29 | 77.09 | 9.38 | 64.12 | -23.70 | 283.87 | 48.45 | 238.56 | 0.8054 | 884.3 | 306.8 | |
| 4.62 | -1.00 | 3.85 | -1.00 | -24.13 | 283.84 | 48.42 | 238.06 | 0.8067 | 661.9 | 999999 | |
| 0.00 | 0.94 | 0.00 | 0.78 | -24.35 | 283.56 | 48.14 | 237.68 | 0.8051 | 501.0 | 437.0 | |
| 0.00 | 2.14 | 0.00 | 1.68 | -21.61 | 281.82 | 46.40 | 240.16 | 0.7785 | 458.0 | 448.6 | |
| 0.00 | 0.94 | 0.00 | 0.74 | -21.94 | 281.77 | 46.35 | 239.75 | 0.7793 | 543.0 | 435.1 | |
| 0.00 | 0.68 | 0.00 | 0.54 | -21.90 | 281.52 | 46.10 | 239.69 | 0.7768 | 565.0 | 504.2 | |
| 0.00 | 1.20 | 0.00 | 0.90 | -23.35 | 278.42 | 43.00 | 236.45 | 0.7536 | -593.0 | -501.1 | |
| 0.00 | 1.80 | 0.00 | 1.35 | -23.81 | 278.47 | 43.05 | 235.93 | 0.7563 | -601.0 | -529.0 | |
| 0.00 | 1.54 | 0.00 | 1.15 | -24.10 | 277.97 | 42.55 | 235.33 | 0.7530 | -532.0 | -418.2 | |
| 0.00 | 1.11 | 0.00 | 0.83 | -26.97 | 275.59 | 40.17 | 230.58 | 0.7465 | -432.0 | -445.2 | |
| 0.00 | 1.28 | 0.00 | 0.94 | -27.95 | 273.89 | 38.47 | 228.40 | 0.7373 | -650.0 | -495.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
