SDO HMI 2011-11-26 13:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 127.91 | 561.05 | 79.01 | 344.42 | 19.42 | 192.47 | -31.98 | 58.00 | 0.5899 | -289.6 | -127.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-11-26 13:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.86 | 0.00 | 0.49 | 16.06 | 198.60 | -25.85 | 58.78 | 0.4920 | -571.0 | -444.1 | |
| 51.16 | 419.55 | 30.53 | 252.10 | 18.57 | 194.57 | -29.88 | 57.85 | 0.5600 | -1125.9 | -342.2 | |
| 10.10 | -2.00 | 6.08 | -2.00 | 18.68 | 193.75 | -30.70 | 58.28 | 0.5708 | -1016.1 | 999999 | |
| 1.63 | -2.00 | 0.99 | -2.00 | 19.49 | 193.47 | -30.98 | 57.23 | 0.5793 | -702.3 | 999999 | |
| 20.53 | -2.00 | 12.42 | -2.00 | 19.08 | 193.52 | -30.93 | 57.82 | 0.5761 | -895.4 | 999999 | |
| 1.20 | -2.00 | 0.73 | -2.00 | 19.82 | 193.03 | -31.42 | 57.03 | 0.5867 | -435.6 | 999999 | |
| 1.97 | -2.00 | 1.20 | -2.00 | 19.17 | 193.13 | -31.31 | 57.96 | 0.5813 | -541.1 | 999999 | |
| 1.88 | -2.00 | 1.15 | -2.00 | 19.17 | 192.95 | -31.50 | 58.10 | 0.5835 | -507.4 | 999999 | |
| 0.00 | 1.28 | 0.00 | 0.77 | 17.99 | 193.16 | -31.29 | 59.79 | 0.5738 | -143.0 | -124.1 | |
| 1.03 | -2.00 | 0.63 | -2.00 | 19.41 | 192.75 | -31.70 | 57.86 | 0.5875 | -560.1 | 999999 | |
| 0.00 | 0.34 | 0.00 | 0.21 | 20.27 | 191.02 | -33.43 | 57.77 | 0.6132 | -458.0 | -302.8 | |
| 0.00 | 1.20 | 0.00 | 0.75 | 19.58 | 190.92 | -33.53 | 58.86 | 0.6103 | 660.0 | 653.8 | |
| 20.36 | 86.07 | 13.01 | 54.93 | 20.43 | 189.29 | -35.15 | 58.63 | 0.6342 | 1010.0 | 529.5 | |
| 0.00 | 0.86 | 0.00 | 0.56 | 23.07 | 188.06 | -36.39 | 55.70 | 0.6631 | 603.0 | 484.7 | |
| 0.00 | 0.86 | 0.00 | 0.56 | 22.75 | 188.12 | -36.33 | 56.09 | 0.6606 | 762.0 | 581.2 | |
| 0.00 | 1.28 | 0.00 | 0.87 | 24.46 | 186.70 | -37.75 | 54.66 | 0.6855 | 532.0 | 495.4 | |
| 0.00 | 1.11 | 0.00 | 0.70 | 14.99 | 188.85 | -35.59 | 67.05 | 0.6128 | -691.0 | -497.3 | |
| 0.00 | 1.37 | 0.00 | 0.91 | 21.28 | 186.85 | -37.60 | 58.86 | 0.6666 | 696.0 | 575.4 | |
| 4.02 | 7.44 | 2.72 | 5.02 | 22.50 | 186.02 | -38.43 | 57.66 | 0.6821 | 865.1 | 576.5 | |
| 1.71 | 25.75 | 1.16 | 17.55 | 22.94 | 185.74 | -38.70 | 57.22 | 0.6873 | 686.2 | 625.3 | |
| 4.88 | -20.00 | 3.31 | -20.00 | 22.62 | 185.65 | -38.80 | 57.70 | 0.6867 | 859.6 | 999999 | |
| 0.00 | 2.05 | 0.00 | 1.39 | 22.15 | 185.80 | -38.64 | 58.25 | 0.6826 | 843.0 | 662.5 | |
| 7.44 | -20.00 | 5.08 | -20.00 | 22.68 | 185.30 | -39.15 | 57.81 | 0.6907 | 787.5 | 999999 | |
| 0.00 | 2.22 | 0.00 | 1.53 | 23.15 | 185.13 | -39.32 | 57.26 | 0.6949 | 494.0 | 478.8 | |
| 0.00 | 4.53 | 0.00 | 3.13 | 23.02 | 184.80 | -39.64 | 57.61 | 0.6977 | 456.0 | 406.3 | |
| 0.00 | 2.48 | 0.00 | 1.71 | 22.67 | 184.59 | -39.86 | 58.19 | 0.6982 | 629.0 | 564.3 | |
| 0.00 | 1.80 | 0.00 | 1.24 | 22.54 | 184.43 | -40.02 | 58.45 | 0.6993 | 393.0 | 354.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
