SDO HMI 2011-11-26 14:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 17.97 | 0.00 | 12.73 | -16.19 | 266.51 | 42.61 | 245.39 | 0.7179 | 100.8 | 215.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-11-26 14:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.80 | 0.00 | 1.29 | -11.72 | 268.62 | 44.73 | 252.20 | 0.7261 | 707.0 | 616.4 | |
| 0.00 | 1.54 | 0.00 | 1.11 | -13.46 | 268.67 | 44.77 | 249.90 | 0.7317 | 553.0 | 474.3 | |
| 0.00 | 0.77 | 0.00 | 0.56 | -13.88 | 268.30 | 44.40 | 249.21 | 0.7289 | 495.0 | 453.1 | |
| 0.00 | 0.77 | 0.00 | 0.55 | -11.92 | 267.82 | 43.92 | 251.67 | 0.7173 | 732.0 | 597.4 | |
| 0.00 | 5.13 | 0.00 | 3.72 | -16.93 | 267.70 | 43.80 | 244.98 | 0.7331 | 911.0 | 600.3 | |
| 0.00 | 1.20 | 0.00 | 0.86 | -19.67 | 266.33 | 42.43 | 240.83 | 0.7299 | 607.0 | 432.6 | |
| 0.00 | 1.03 | 0.00 | 0.72 | -17.92 | 265.49 | 41.59 | 242.69 | 0.7132 | -601.0 | -468.3 | |
| 0.00 | 0.60 | 0.00 | 0.41 | -14.80 | 264.48 | 40.58 | 246.43 | 0.6886 | -626.0 | -505.4 | |
| 0.00 | 1.71 | 0.00 | 1.19 | -18.07 | 264.87 | 40.97 | 242.20 | 0.7071 | -212.0 | -268.5 | |
| 0.00 | 0.94 | 0.00 | 0.66 | -19.01 | 265.02 | 41.13 | 241.03 | 0.7131 | -632.0 | -492.0 | |
| 0.00 | 1.45 | 0.00 | 0.99 | -17.17 | 263.64 | 39.75 | 242.78 | 0.6893 | -154.0 | -212.1 | |
| 0.00 | 1.03 | 0.00 | 0.67 | -17.65 | 260.83 | 36.93 | 240.58 | 0.6597 | -571.0 | -533.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
