SDO HMI 2011-11-26 15:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 51.75 | 294.93 | 26.70 | 152.15 | 17.63 | 223.39 | 0.05 | 359.91 | 0.2798 | -738.7 | -380.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-11-26 15:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.71 | 0.00 | 0.90 | 20.89 | 228.24 | 4.89 | 346.51 | 0.3432 | -801.0 | -500.9 | |
| 0.00 | 6.07 | 0.00 | 3.16 | 18.71 | 228.01 | 4.67 | 345.41 | 0.3074 | -803.0 | -732.3 | |
| 0.00 | 1.80 | 0.00 | 0.94 | 19.02 | 227.84 | 4.49 | 346.20 | 0.3117 | -713.0 | -572.2 | |
| 0.00 | 1.45 | 0.00 | 0.76 | 18.99 | 226.02 | 2.67 | 351.66 | 0.3054 | 906.0 | 637.5 | |
| 14.11 | 237.88 | 7.27 | 122.65 | 17.30 | 223.95 | 0.60 | 357.90 | 0.2738 | -1319.7 | -455.6 | |
| 27.03 | -5.00 | 13.95 | -5.00 | 17.76 | 223.33 | -0.02 | 0.06 | 0.2814 | -1316.3 | 999999 | |
| 0.94 | -5.00 | 0.48 | -5.00 | 17.24 | 223.33 | -0.02 | 0.07 | 0.2726 | -922.1 | 999999 | |
| 0.00 | 1.97 | 0.00 | 1.01 | 16.29 | 222.50 | -0.85 | 3.19 | 0.2569 | -808.0 | -611.2 | |
| 0.00 | 1.28 | 0.00 | 0.67 | 19.93 | 222.23 | -1.12 | 3.32 | 0.3182 | -785.0 | -614.2 | |
| 9.67 | 24.38 | 5.00 | 12.61 | 18.04 | 222.02 | -1.32 | 4.41 | 0.2869 | -1026.7 | -353.8 | |
| 0.00 | 1.11 | 0.00 | 0.57 | 17.51 | 221.84 | -1.51 | 5.19 | 0.2784 | -831.0 | -614.2 | |
| 0.00 | 1.03 | 0.00 | 0.52 | 15.13 | 221.76 | -1.58 | 6.44 | 0.2383 | 939.0 | 777.2 | |
| 0.00 | 2.22 | 0.00 | 1.15 | 17.67 | 221.34 | -2.01 | 6.82 | 0.2818 | -801.0 | -520.2 | |
| 0.00 | 4.79 | 0.00 | 2.45 | 15.58 | 221.33 | -2.01 | 7.92 | 0.2470 | 975.0 | 879.9 | |
| 0.00 | 2.91 | 0.00 | 1.49 | 15.40 | 221.06 | -2.29 | 9.10 | 0.2446 | 698.0 | 702.8 | |
| 0.00 | 2.05 | 0.00 | 1.06 | 18.16 | 220.74 | -2.60 | 8.55 | 0.2914 | 782.0 | 560.2 | |
| 0.00 | 0.94 | 0.00 | 0.48 | 14.55 | 220.45 | -2.89 | 12.19 | 0.2322 | 949.0 | 800.3 | |
| 0.00 | 1.11 | 0.00 | 0.58 | 19.06 | 219.88 | -3.46 | 10.71 | 0.3086 | 628.0 | 538.2 | |
| 0.00 | 0.86 | 0.00 | 0.44 | 17.11 | 219.89 | -3.45 | 12.07 | 0.2766 | 910.0 | 720.0 | |
| 0.00 | 1.37 | 0.00 | 0.71 | 18.53 | 219.80 | -3.54 | 11.31 | 0.3002 | 929.0 | 728.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
