SDO HMI 2011-11-27 05:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 118.52 | 565.03 | 67.50 | 320.15 | 19.37 | 192.49 | -23.15 | 49.92 | 0.4849 | -218.3 | -209.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-11-27 05:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.71 | 0.00 | 0.93 | 16.10 | 196.58 | -19.06 | 50.90 | 0.4060 | -971.0 | -797.2 | |
| 3.08 | 398.05 | 1.70 | 221.59 | 18.21 | 195.19 | -20.44 | 48.78 | 0.4430 | -1091.0 | -453.3 | |
| 1.03 | -2.00 | 0.57 | -2.00 | 19.42 | 194.90 | -20.73 | 47.05 | 0.4581 | -768.8 | 999999 | |
| 32.26 | -2.00 | 17.90 | -2.00 | 18.55 | 194.62 | -21.02 | 48.93 | 0.4530 | -1320.9 | 999999 | |
| 0.60 | -2.00 | 0.33 | -2.00 | 18.02 | 194.48 | -21.15 | 50.04 | 0.4496 | -835.0 | 999999 | |
| 0.00 | 1.03 | 0.00 | 0.58 | 20.32 | 193.97 | -21.67 | 46.75 | 0.4774 | -713.0 | -648.8 | |
| 12.07 | -2.00 | 6.72 | -2.00 | 18.51 | 194.09 | -21.55 | 49.66 | 0.4589 | -1121.5 | 999999 | |
| 12.75 | -2.00 | 7.13 | -2.00 | 18.88 | 193.87 | -21.77 | 49.28 | 0.4649 | -964.6 | 999999 | |
| 0.00 | 1.28 | 0.00 | 0.73 | 21.10 | 193.54 | -22.10 | 46.02 | 0.4897 | -821.0 | -663.4 | |
| 4.02 | -2.00 | 2.26 | -2.00 | 19.57 | 193.74 | -21.90 | 48.28 | 0.4728 | -831.4 | 999999 | |
| 2.31 | -2.00 | 1.30 | -2.00 | 19.35 | 193.74 | -21.90 | 48.65 | 0.4708 | -898.5 | 999999 | |
| 1.28 | -2.00 | 0.72 | -2.00 | 19.16 | 193.63 | -22.01 | 49.10 | 0.4703 | -734.0 | 999999 | |
| 0.51 | -2.00 | 0.29 | -2.00 | 19.56 | 193.33 | -22.31 | 48.78 | 0.4775 | -793.2 | 999999 | |
| 0.00 | 0.86 | 0.00 | 0.49 | 21.47 | 192.28 | -23.36 | 46.94 | 0.5072 | -530.0 | -493.8 | |
| 1.37 | 1.80 | 0.78 | 1.02 | 19.49 | 192.12 | -23.52 | 50.30 | 0.4910 | -475.3 | -643.4 | |
| 2.65 | 4.28 | 1.52 | 2.45 | 19.92 | 191.57 | -24.07 | 50.19 | 0.5013 | 861.1 | 398.3 | |
| 0.00 | 1.11 | 0.00 | 0.62 | 16.67 | 191.87 | -23.77 | 55.50 | 0.4704 | -712.0 | -535.1 | |
| 2.91 | 4.11 | 1.67 | 2.35 | 19.07 | 190.81 | -24.83 | 52.40 | 0.5030 | -728.1 | -707.5 | |
| 0.00 | 1.20 | 0.00 | 0.69 | 20.66 | 190.54 | -25.10 | 50.09 | 0.5196 | -651.0 | -482.4 | |
| 0.00 | 1.11 | 0.00 | 0.64 | 20.41 | 190.55 | -25.09 | 50.48 | 0.5173 | -170.0 | -162.1 | |
| 1.03 | 2.82 | 0.58 | 1.58 | 15.29 | 191.11 | -24.53 | 58.85 | 0.4700 | -748.8 | -680.7 | |
| 0.00 | 1.11 | 0.00 | 0.64 | 19.29 | 190.46 | -25.18 | 52.40 | 0.5089 | -576.0 | -439.4 | |
| 3.68 | 27.22 | 2.13 | 15.78 | 20.10 | 190.18 | -25.46 | 51.36 | 0.5189 | 1097.0 | 607.0 | |
| 3.42 | -23.00 | 1.99 | -23.00 | 20.12 | 189.90 | -25.74 | 51.60 | 0.5225 | 948.3 | 999999 | |
| 0.00 | 2.40 | 0.00 | 1.42 | 21.91 | 188.67 | -26.97 | 50.03 | 0.5512 | 914.0 | 701.8 | |
| 23.36 | 77.88 | 13.73 | 45.76 | 20.68 | 188.77 | -26.87 | 51.81 | 0.5400 | 1038.3 | 456.6 | |
| 4.54 | -26.00 | 2.68 | -26.00 | 20.86 | 188.17 | -27.47 | 52.09 | 0.5485 | 696.4 | 999999 | |
| 0.00 | 0.94 | 0.00 | 0.56 | 20.95 | 187.76 | -27.88 | 52.33 | 0.5540 | 674.0 | 424.5 | |
| 0.00 | 1.28 | 0.00 | 0.79 | 22.60 | 185.64 | -30.00 | 51.69 | 0.5905 | 866.0 | 765.9 | |
| 0.00 | 0.94 | 0.00 | 0.58 | 22.92 | 185.45 | -30.19 | 51.40 | 0.5949 | 918.0 | 694.6 | |
| 1.80 | 14.81 | 1.11 | 9.14 | 23.23 | 185.15 | -30.49 | 51.19 | 0.6006 | 688.8 | 762.3 | |
| 1.20 | -31.00 | 0.74 | -31.00 | 23.07 | 185.04 | -30.60 | 51.51 | 0.6006 | 879.0 | 999999 | |
| 0.00 | 0.94 | 0.00 | 0.54 | 11.61 | 187.09 | -28.55 | 68.95 | 0.5037 | 753.0 | 492.4 | |
| 0.00 | 0.94 | 0.00 | 0.59 | 24.06 | 184.74 | -30.90 | 50.36 | 0.6111 | 599.0 | 528.7 | |
| 1.37 | 5.22 | 0.85 | 3.24 | 23.01 | 184.76 | -30.88 | 51.83 | 0.6032 | 769.9 | 631.7 | |
| 0.00 | 0.86 | 0.00 | 0.53 | 23.20 | 184.56 | -31.08 | 51.72 | 0.6068 | 699.0 | 584.7 | |
| 0.00 | 1.11 | 0.00 | 0.69 | 23.39 | 184.47 | -31.17 | 51.52 | 0.6091 | 564.0 | 432.3 | |
| 0.00 | 1.03 | 0.00 | 0.64 | 22.59 | 184.64 | -31.00 | 52.52 | 0.6015 | 560.0 | 538.2 | |
| 0.00 | 2.82 | 0.00 | 1.76 | 23.19 | 184.33 | -31.31 | 51.90 | 0.6092 | 647.0 | 366.7 | |
| 1.28 | 2.57 | 0.80 | 1.60 | 22.87 | 184.30 | -31.34 | 52.38 | 0.6073 | 773.9 | 654.1 | |
| 0.00 | 0.60 | 0.00 | 0.37 | 22.90 | 183.92 | -31.72 | 52.64 | 0.6117 | 606.0 | 529.3 | |
| 0.00 | 1.37 | 0.00 | 0.85 | 22.71 | 183.89 | -31.75 | 52.93 | 0.6106 | 620.0 | 492.0 | |
| 0.00 | 1.63 | 0.00 | 1.00 | 20.68 | 183.64 | -32.00 | 56.06 | 0.5998 | 703.0 | 609.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
