SDO HMI 2011-11-27 14:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 43.10 | 306.05 | 23.94 | 169.52 | 15.66 | 233.37 | 22.65 | 303.87 | 0.4489 | -914.4 | -403.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-11-27 14:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.03 | 0.00 | 0.58 | 13.61 | 237.95 | 27.23 | 295.77 | 0.4958 | -686.0 | -492.2 | |
| 0.00 | 2.65 | 0.00 | 1.50 | 17.89 | 235.08 | 24.36 | 306.11 | 0.4879 | -852.0 | -687.7 | |
| 0.00 | 1.11 | 0.00 | 0.61 | 12.98 | 234.44 | 23.72 | 297.41 | 0.4434 | -779.0 | -640.9 | |
| 2.22 | 2.91 | 1.26 | 1.65 | 18.45 | 235.06 | 24.34 | 307.10 | 0.4922 | -728.6 | -502.1 | |
| 0.00 | 2.65 | 0.00 | 1.50 | 18.17 | 234.85 | 24.13 | 306.84 | 0.4874 | -901.0 | -724.9 | |
| 2.14 | 2.99 | 1.21 | 1.69 | 18.29 | 234.66 | 23.94 | 307.26 | 0.4861 | -911.0 | -823.6 | |
| 0.00 | 1.45 | 0.00 | 0.80 | 12.84 | 233.60 | 22.88 | 297.90 | 0.4308 | -928.0 | -697.4 | |
| 36.00 | 264.41 | 19.95 | 146.52 | 15.36 | 233.67 | 22.95 | 302.93 | 0.4499 | -1433.3 | -408.1 | |
| 2.74 | -8.00 | 1.52 | -8.00 | 15.81 | 233.45 | 22.74 | 304.05 | 0.4507 | -1050.5 | 999999 | |
| 0.00 | 1.62 | 0.00 | 0.91 | 18.03 | 233.23 | 22.52 | 308.38 | 0.4665 | -432.0 | -483.8 | |
| 0.00 | 2.31 | 0.00 | 1.26 | 14.54 | 232.42 | 21.70 | 302.68 | 0.4270 | -848.0 | -667.9 | |
| 0.00 | 1.37 | 0.00 | 0.77 | 19.27 | 232.56 | 21.85 | 311.35 | 0.4698 | -878.0 | -748.1 | |
| 0.00 | 2.05 | 0.00 | 1.12 | 14.12 | 231.75 | 21.04 | 302.57 | 0.4148 | -724.0 | -619.2 | |
| 0.00 | 1.28 | 0.00 | 0.72 | 19.77 | 232.36 | 21.65 | 312.43 | 0.4723 | -600.0 | -542.3 | |
| 0.00 | 1.28 | 0.00 | 0.71 | 19.22 | 231.31 | 20.59 | 312.84 | 0.4549 | -715.0 | -569.6 | |
| 0.00 | 0.68 | 0.00 | 0.38 | 19.16 | 231.04 | 20.32 | 313.11 | 0.4512 | -681.0 | -529.1 | |
| 0.00 | 1.80 | 0.00 | 0.99 | 18.39 | 230.18 | 19.46 | 312.93 | 0.4336 | -643.0 | -570.4 | |
| 0.00 | 1.80 | 0.00 | 0.98 | 18.24 | 229.76 | 19.05 | 313.25 | 0.4273 | -742.0 | -508.2 | |
| 0.00 | 1.11 | 0.00 | 0.61 | 18.37 | 229.45 | 18.73 | 313.93 | 0.4250 | -706.0 | -511.2 | |
| 0.00 | 1.37 | 0.00 | 0.76 | 21.27 | 229.07 | 18.35 | 319.34 | 0.4522 | -609.0 | -496.3 | |
| 0.00 | 1.20 | 0.00 | 0.66 | 21.43 | 228.96 | 18.24 | 319.75 | 0.4528 | -642.0 | -525.9 | |
| 0.00 | 1.71 | 0.00 | 0.95 | 22.48 | 227.79 | 17.07 | 323.10 | 0.4536 | -558.0 | -388.8 | |
| 0.00 | 2.48 | 0.00 | 1.30 | 13.19 | 226.48 | 15.76 | 307.89 | 0.3366 | 772.0 | 532.8 | |
| 0.00 | 0.86 | 0.00 | 0.46 | 16.51 | 226.47 | 15.76 | 315.19 | 0.3710 | 781.0 | 614.7 | |
| 0.00 | 2.22 | 0.00 | 1.19 | 16.69 | 226.33 | 15.61 | 315.81 | 0.3714 | 841.0 | 672.6 | |
| 0.00 | 1.71 | 0.00 | 0.90 | 14.77 | 225.86 | 15.14 | 312.64 | 0.3449 | 732.0 | 562.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
