SDO HMI 2011-11-28 05:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 23.61 | 148.18 | 18.61 | 116.23 | 14.48 | 252.10 | 49.64 | 287.76 | 0.7769 | -597.0 | -276.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-11-28 05:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 23.10 | 135.00 | 18.21 | 106.52 | 14.33 | 252.44 | 49.98 | 287.47 | 0.7802 | -984.7 | -302.5 | |
| 0.00 | 1.28 | 0.00 | 1.00 | 13.49 | 251.95 | 49.49 | 286.50 | 0.7735 | -217.0 | -218.5 | |
| 0.51 | 1.54 | 0.40 | 1.19 | 14.65 | 251.54 | 49.08 | 288.08 | 0.7714 | -706.8 | -663.5 | |
| 0.00 | 0.86 | 0.00 | 0.67 | 16.58 | 251.37 | 48.91 | 290.58 | 0.7739 | -554.0 | -483.4 | |
| 0.00 | 1.37 | 0.00 | 1.07 | 17.02 | 251.28 | 48.82 | 291.15 | 0.7740 | -496.0 | -474.5 | |
| 0.00 | 1.71 | 0.00 | 1.33 | 17.08 | 251.12 | 48.66 | 291.28 | 0.7725 | -729.0 | -654.5 | |
| 0.00 | 0.94 | 0.00 | 0.67 | 13.56 | 247.42 | 44.96 | 287.68 | 0.7234 | 576.0 | 502.7 | |
| 0.00 | 1.03 | 0.00 | 0.73 | 13.74 | 247.47 | 45.01 | 287.92 | 0.7244 | 529.0 | 425.8 | |
| 0.00 | 1.37 | 0.00 | 0.94 | 17.62 | 243.76 | 41.30 | 294.50 | 0.6936 | 614.0 | 473.1 | |
| 0.00 | 1.03 | 0.00 | 0.70 | 17.19 | 243.43 | 40.97 | 294.04 | 0.6883 | 647.0 | 544.1 | |
| 0.00 | 0.94 | 0.00 | 0.65 | 18.33 | 243.67 | 41.21 | 295.52 | 0.6954 | 394.0 | 391.9 | |
| 0.00 | 1.11 | 0.00 | 0.76 | 18.18 | 243.54 | 41.08 | 295.36 | 0.6933 | 479.0 | 538.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
