SDO HMI 2011-11-29 07:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 13.43 | 86.28 | 15.56 | 100.12 | 14.51 | 252.20 | 64.01 | 285.55 | 0.9050 | -571.1 | -172.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-11-29 07:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 13.43 | 82.86 | 15.56 | 96.42 | 14.50 | 252.28 | 64.09 | 285.53 | 0.9056 | -664.6 | -170.3 | |
| 0.00 | 1.03 | 0.00 | 1.16 | 14.12 | 251.52 | 63.33 | 285.19 | 0.8998 | -614.0 | -548.1 | |
| 0.00 | 0.94 | 0.00 | 1.04 | 13.98 | 250.97 | 62.78 | 285.09 | 0.8956 | -329.0 | -248.5 | |
| 0.00 | 0.77 | 0.00 | 0.85 | 15.35 | 250.87 | 62.68 | 286.63 | 0.8960 | -301.0 | -243.6 | |
| 0.00 | 0.68 | 0.00 | 0.65 | 16.76 | 245.72 | 57.53 | 288.99 | 0.8565 | 415.0 | 397.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
