SDO HMI 2011-11-30 02:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 88.32 | 224.90 | 46.32 | 118.16 | 18.98 | 170.69 | -7.05 | 20.14 | 0.3328 | -71.1 | 87.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-11-30 02:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 2.14 | 0.00 | 1.12 | 19.32 | 175.12 | -2.62 | 7.82 | 0.3179 | -906.0 | -735.6 | |
| 6.67 | 77.62 | 3.46 | 40.40 | 18.24 | 174.08 | -3.66 | 11.59 | 0.3030 | -1061.9 | -511.9 | |
| 0.51 | -2.00 | 0.27 | -2.00 | 18.61 | 174.04 | -3.70 | 11.46 | 0.3092 | 128.3 | 999999 | |
| 3.42 | -2.00 | 1.77 | -2.00 | 18.02 | 173.90 | -3.84 | 12.31 | 0.3001 | -1195.6 | 999999 | |
| 26.59 | -2.00 | 13.83 | -2.00 | 18.45 | 173.67 | -4.07 | 12.69 | 0.3080 | -1124.7 | 999999 | |
| 0.00 | 2.05 | 0.00 | 1.07 | 18.61 | 173.07 | -4.67 | 14.34 | 0.3128 | -750.0 | -633.2 | |
| 0.00 | 1.54 | 0.00 | 0.80 | 18.42 | 173.05 | -4.69 | 14.58 | 0.3099 | -746.0 | -639.1 | |
| 0.00 | 1.20 | 0.00 | 0.62 | 18.79 | 172.85 | -4.89 | 14.84 | 0.3167 | -656.0 | -506.9 | |
| 0.00 | 4.79 | 0.00 | 2.49 | 18.05 | 172.81 | -4.93 | 15.62 | 0.3050 | -496.0 | -684.5 | |
| 1.54 | 1.97 | 0.80 | 1.03 | 18.64 | 172.63 | -5.11 | 15.60 | 0.3152 | -844.2 | -874.8 | |
| 0.00 | 1.37 | 0.00 | 0.71 | 18.70 | 172.41 | -5.33 | 16.18 | 0.3172 | -701.0 | -593.2 | |
| 0.00 | 0.85 | 0.00 | 0.45 | 18.57 | 172.07 | -5.67 | 17.27 | 0.3168 | -553.0 | -382.7 | |
| 0.00 | 0.85 | 0.00 | 0.45 | 20.73 | 171.71 | -6.03 | 16.27 | 0.3524 | -864.0 | -590.7 | |
| 8.63 | 13.42 | 4.52 | 7.02 | 18.91 | 171.62 | -6.12 | 18.20 | 0.3244 | -893.7 | -447.2 | |
| 1.97 | 3.25 | 1.03 | 1.70 | 18.23 | 171.02 | -6.72 | 20.62 | 0.3171 | 869.1 | 941.3 | |
| 0.00 | 0.85 | 0.00 | 0.45 | 18.67 | 170.97 | -6.77 | 20.25 | 0.3241 | -590.0 | -416.5 | |
| 2.39 | 3.08 | 1.26 | 1.63 | 19.94 | 169.96 | -7.78 | 21.44 | 0.3495 | -888.5 | -664.4 | |
| 0.00 | 0.94 | 0.00 | 0.49 | 18.82 | 169.96 | -7.78 | 22.78 | 0.3326 | 827.0 | 618.2 | |
| 0.00 | 1.37 | 0.00 | 0.72 | 18.17 | 169.83 | -7.91 | 23.95 | 0.3236 | 872.0 | 673.9 | |
| 0.00 | 1.88 | 0.00 | 0.99 | 19.97 | 169.68 | -8.06 | 22.11 | 0.3517 | -774.0 | -662.9 | |
| 0.00 | 0.85 | 0.00 | 0.45 | 19.13 | 169.50 | -8.24 | 23.57 | 0.3402 | 1020.0 | 806.6 | |
| 0.00 | 1.28 | 0.00 | 0.68 | 19.31 | 169.46 | -8.28 | 23.44 | 0.3433 | 776.0 | 575.3 | |
| 0.00 | 1.28 | 0.00 | 0.67 | 18.54 | 169.21 | -8.53 | 25.06 | 0.3334 | 569.0 | 416.5 | |
| 2.14 | 3.16 | 1.13 | 1.67 | 19.19 | 169.02 | -8.72 | 24.68 | 0.3444 | 929.8 | 808.2 | |
| 1.28 | 2.82 | 0.68 | 1.49 | 18.85 | 168.53 | -9.21 | 26.34 | 0.3428 | 924.0 | 916.7 | |
| 0.00 | 2.05 | 0.00 | 1.09 | 20.75 | 168.42 | -9.32 | 24.18 | 0.3714 | 672.0 | 564.2 | |
| 7.95 | 70.52 | 4.20 | 37.30 | 19.34 | 168.47 | -9.27 | 25.82 | 0.3505 | 1046.5 | 599.8 | |
| 0.00 | 1.11 | 0.00 | 0.59 | 19.87 | 168.38 | -9.36 | 25.35 | 0.3588 | 901.0 | 703.1 | |
| 0.00 | 1.03 | 0.00 | 0.55 | 20.40 | 168.12 | -9.62 | 25.28 | 0.3684 | 807.0 | 673.8 | |
| 6.24 | -27.00 | 3.30 | -27.00 | 19.31 | 168.13 | -9.61 | 26.69 | 0.3525 | 1216.7 | 999999 | |
| 1.80 | 17.35 | 0.96 | 9.25 | 20.59 | 167.98 | -9.76 | 25.36 | 0.3721 | 916.9 | 749.5 | |
| 7.44 | -27.00 | 3.94 | -27.00 | 19.40 | 167.80 | -9.94 | 27.32 | 0.3563 | 980.1 | 999999 | |
| 3.42 | -31.00 | 1.82 | -31.00 | 20.12 | 167.72 | -10.02 | 26.54 | 0.3671 | 1079.1 | 999999 | |
| 6.33 | -27.00 | 3.35 | -27.00 | 19.03 | 167.60 | -10.14 | 28.31 | 0.3524 | 985.4 | 999999 | |
| 0.00 | 1.54 | 0.00 | 0.82 | 19.18 | 167.31 | -10.43 | 28.77 | 0.3569 | 6.0 | 66.4 | |
| 0.00 | 1.20 | 0.00 | 0.64 | 19.52 | 166.52 | -11.22 | 30.04 | 0.3680 | 820.0 | 600.5 | |
| 0.00 | 1.54 | 0.00 | 0.82 | 19.24 | 166.31 | -11.43 | 30.90 | 0.3658 | 933.0 | 646.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
