SDO HMI 2011-11-30 22:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 44.94 | 286.26 | 26.28 | 167.63 | 20.36 | 192.75 | 25.99 | 309.39 | 0.5344 | -231.9 | -227.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-11-30 22:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.94 | 0.00 | 0.57 | 19.07 | 197.18 | 30.42 | 303.19 | 0.5741 | -654.0 | -483.4 | |
| 0.94 | 213.40 | 0.56 | 126.15 | 19.34 | 194.94 | 28.18 | 305.44 | 0.5491 | -831.2 | -407.8 | |
| 33.32 | -2.00 | 19.69 | -2.00 | 19.59 | 194.66 | 27.90 | 306.08 | 0.5477 | -1150.5 | 999999 | |
| 0.00 | 1.20 | 0.00 | 0.72 | 22.52 | 194.47 | 27.71 | 310.68 | 0.5687 | -656.0 | -517.9 | |
| 0.00 | 0.68 | 0.00 | 0.41 | 22.62 | 194.35 | 27.59 | 310.94 | 0.5681 | -698.0 | -561.1 | |
| 0.00 | 1.62 | 0.00 | 0.97 | 22.14 | 193.85 | 27.09 | 310.72 | 0.5588 | -658.0 | -533.7 | |
| 0.00 | 1.28 | 0.00 | 0.74 | 19.19 | 192.73 | 25.97 | 307.26 | 0.5217 | -728.0 | -572.5 | |
| 0.00 | 1.11 | 0.00 | 0.64 | 20.05 | 191.17 | 24.41 | 310.23 | 0.5106 | -843.0 | -634.3 | |
| 0.00 | 1.20 | 0.00 | 0.69 | 21.43 | 191.13 | 24.37 | 312.44 | 0.5226 | -559.0 | -439.7 | |
| 0.00 | 2.05 | 0.00 | 1.19 | 21.18 | 190.98 | 24.22 | 312.21 | 0.5186 | -896.0 | -763.7 | |
| 0.00 | 1.28 | 0.00 | 0.74 | 20.65 | 190.86 | 24.10 | 311.52 | 0.5124 | -820.0 | -703.2 | |
| 0.00 | 1.11 | 0.00 | 0.64 | 20.36 | 190.74 | 23.98 | 311.21 | 0.5085 | -783.0 | -602.7 | |
| 0.00 | 0.68 | 0.00 | 0.38 | 15.55 | 189.32 | 22.56 | 304.40 | 0.4498 | -783.0 | -626.9 | |
| 0.00 | 0.94 | 0.00 | 0.52 | 15.49 | 189.15 | 22.39 | 304.48 | 0.4471 | -674.0 | -611.8 | |
| 0.00 | 1.62 | 0.00 | 0.89 | 15.06 | 188.73 | 21.97 | 304.12 | 0.4383 | -884.0 | -734.6 | |
| 0.00 | 0.94 | 0.00 | 0.52 | 14.85 | 188.65 | 21.88 | 303.80 | 0.4354 | -753.0 | -555.5 | |
| 0.00 | 0.60 | 0.00 | 0.34 | 21.10 | 188.56 | 21.80 | 314.92 | 0.4913 | 624.0 | 472.0 | |
| 0.00 | 1.45 | 0.00 | 0.83 | 22.28 | 187.75 | 20.99 | 317.72 | 0.4947 | 1001.0 | 797.3 | |
| 0.00 | 1.79 | 0.00 | 1.01 | 21.61 | 187.04 | 20.27 | 317.67 | 0.4804 | 765.0 | 610.0 | |
| 4.19 | 4.87 | 2.37 | 2.75 | 22.28 | 186.69 | 19.93 | 319.13 | 0.4841 | 833.9 | 734.0 | |
| 2.39 | 2.90 | 1.35 | 1.64 | 22.60 | 186.23 | 19.47 | 320.23 | 0.4830 | 749.4 | 504.3 | |
| 0.00 | 2.22 | 0.00 | 1.25 | 22.70 | 185.97 | 19.21 | 320.73 | 0.4816 | 712.0 | 472.6 | |
| 0.00 | 2.39 | 0.00 | 1.35 | 22.54 | 185.71 | 18.95 | 320.87 | 0.4773 | 743.0 | 756.4 | |
| 0.00 | 5.30 | 0.00 | 2.97 | 22.25 | 185.60 | 18.84 | 320.61 | 0.4730 | 660.0 | 654.2 | |
| 3.25 | 4.19 | 1.83 | 2.35 | 22.93 | 185.12 | 18.36 | 322.26 | 0.4760 | 892.4 | 843.5 | |
| 0.00 | 1.20 | 0.00 | 0.68 | 24.05 | 185.29 | 18.53 | 323.55 | 0.4905 | 760.0 | 585.8 | |
| 0.00 | 0.94 | 0.00 | 0.55 | 26.81 | 185.60 | 18.84 | 326.59 | 0.5254 | 498.0 | 437.0 | |
| 0.00 | 3.08 | 0.00 | 1.73 | 23.21 | 185.00 | 18.24 | 322.85 | 0.4782 | 711.0 | 670.1 | |
| 0.00 | 1.62 | 0.00 | 0.92 | 23.37 | 184.98 | 18.22 | 323.08 | 0.4799 | 773.0 | 608.6 | |
| 0.00 | 1.37 | 0.00 | 0.79 | 26.88 | 185.47 | 18.71 | 326.84 | 0.5251 | 536.0 | 433.6 | |
| 0.00 | 1.88 | 0.00 | 1.06 | 22.93 | 184.79 | 18.03 | 322.75 | 0.4729 | 965.0 | 818.9 | |
| 0.00 | 1.96 | 0.00 | 1.13 | 25.99 | 185.25 | 18.49 | 326.08 | 0.5129 | 647.0 | 502.7 | |
| 0.00 | 2.31 | 0.00 | 1.30 | 23.57 | 184.81 | 18.05 | 323.60 | 0.4805 | 793.0 | 704.5 | |
| 0.00 | 2.39 | 0.00 | 1.38 | 26.51 | 185.23 | 18.47 | 326.74 | 0.5190 | 703.0 | 671.6 | |
| 0.00 | 7.09 | 0.00 | 4.07 | 25.83 | 184.95 | 18.18 | 326.31 | 0.5085 | 612.0 | 717.4 | |
| 0.00 | 0.94 | 0.00 | 0.53 | 22.99 | 184.49 | 17.73 | 323.28 | 0.4709 | 867.0 | 722.4 | |
| 0.00 | 0.85 | 0.00 | 0.49 | 25.50 | 184.76 | 18.00 | 326.18 | 0.5030 | 733.0 | 477.7 | |
| 0.85 | 4.10 | 0.48 | 2.31 | 23.89 | 184.31 | 17.55 | 324.76 | 0.4799 | 857.6 | 692.6 | |
| 0.00 | 0.77 | 0.00 | 0.43 | 23.63 | 184.17 | 17.41 | 324.63 | 0.4756 | 538.0 | 533.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
