SDO HMI 2011-12-01 18:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 64.72 | 276.03 | 35.15 | 150.26 | 18.95 | 172.46 | 16.67 | 319.16 | 0.4158 | -154.4 | -197.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-12-01 18:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.28 | 0.00 | 0.71 | 18.57 | 175.45 | 19.66 | 313.73 | 0.4432 | 577.0 | 413.1 | |
| 0.00 | 1.02 | 0.00 | 0.57 | 20.54 | 175.27 | 19.48 | 317.23 | 0.4618 | -638.0 | -465.3 | |
| 0.00 | 1.37 | 0.00 | 0.74 | 16.81 | 174.76 | 18.97 | 311.54 | 0.4175 | -731.0 | -532.8 | |
| 26.38 | 153.17 | 14.46 | 83.99 | 18.67 | 174.21 | 18.42 | 315.69 | 0.4303 | -1217.8 | -421.0 | |
| 2.56 | -4.00 | 1.40 | -4.00 | 18.98 | 173.98 | 18.19 | 316.57 | 0.4312 | -899.0 | 999999 | |
| 1.37 | -4.00 | 0.75 | -4.00 | 19.01 | 173.43 | 17.64 | 317.47 | 0.4256 | -889.9 | 999999 | |
| 0.00 | 1.62 | 0.00 | 0.88 | 17.90 | 173.11 | 17.32 | 316.03 | 0.4099 | -852.0 | -626.5 | |
| 7.34 | 8.45 | 4.01 | 4.61 | 19.01 | 173.07 | 17.28 | 318.04 | 0.4218 | -996.2 | -813.8 | |
| 0.00 | 2.56 | 0.00 | 1.40 | 19.67 | 173.14 | 17.35 | 319.01 | 0.4299 | -820.0 | -632.9 | |
| 0.00 | 0.94 | 0.00 | 0.51 | 19.61 | 172.87 | 17.08 | 319.34 | 0.4264 | -688.0 | -472.3 | |
| 1.45 | 2.05 | 0.79 | 1.12 | 19.02 | 172.58 | 16.78 | 318.84 | 0.4166 | -905.3 | -942.9 | |
| 0.00 | 1.02 | 0.00 | 0.56 | 20.83 | 172.41 | 16.62 | 322.00 | 0.4361 | -677.0 | -527.5 | |
| 1.88 | 29.28 | 1.02 | 15.88 | 18.92 | 172.01 | 16.22 | 319.62 | 0.4097 | -965.8 | -613.6 | |
| 3.84 | -13.00 | 2.08 | -13.00 | 19.05 | 171.77 | 15.97 | 320.25 | 0.4086 | -1040.1 | 999999 | |
| 0.00 | 3.76 | 0.00 | 2.02 | 17.90 | 171.53 | 15.73 | 318.70 | 0.3927 | -924.0 | -586.5 | |
| 0.00 | 1.79 | 0.00 | 0.97 | 18.21 | 171.39 | 15.60 | 319.48 | 0.3949 | 799.0 | 552.9 | |
| 2.82 | 4.01 | 1.52 | 2.16 | 18.21 | 171.07 | 15.28 | 320.05 | 0.3916 | 879.0 | 728.8 | |
| 0.00 | 0.68 | 0.00 | 0.37 | 19.64 | 171.04 | 15.25 | 322.48 | 0.4085 | -312.0 | -282.6 | |
| 0.00 | 5.04 | 0.00 | 2.71 | 18.49 | 170.68 | 14.88 | 321.25 | 0.3909 | 877.0 | 670.9 | |
| 0.00 | 1.02 | 0.00 | 0.55 | 19.52 | 170.74 | 14.95 | 322.82 | 0.4040 | -681.0 | -454.8 | |
| 0.00 | 1.02 | 0.00 | 0.55 | 18.28 | 170.59 | 14.80 | 321.03 | 0.3874 | 801.0 | 619.2 | |
| 0.00 | 0.60 | 0.00 | 0.32 | 17.94 | 170.18 | 14.39 | 321.22 | 0.3791 | 761.0 | 599.9 | |
| 0.00 | 1.45 | 0.00 | 0.79 | 20.40 | 170.08 | 14.28 | 325.38 | 0.4088 | 744.0 | 559.8 | |
| 0.00 | 0.43 | 0.00 | 0.23 | 20.09 | 169.69 | 13.90 | 325.63 | 0.4013 | 511.0 | 553.4 | |
| 0.00 | 1.11 | 0.00 | 0.60 | 20.12 | 169.53 | 13.74 | 325.98 | 0.4003 | 803.0 | 676.9 | |
| 0.00 | 0.77 | 0.00 | 0.41 | 20.03 | 169.26 | 13.47 | 326.35 | 0.3967 | 942.0 | 733.4 | |
| 1.11 | 3.42 | 0.60 | 1.85 | 20.46 | 169.27 | 13.48 | 326.98 | 0.4025 | 833.3 | 764.2 | |
| 4.27 | 5.21 | 2.29 | 2.79 | 19.28 | 168.88 | 13.08 | 325.96 | 0.3835 | 980.6 | 643.0 | |
| 0.00 | 0.77 | 0.00 | 0.41 | 20.28 | 168.96 | 13.17 | 327.30 | 0.3973 | 818.0 | 708.7 | |
| 0.00 | 1.20 | 0.00 | 0.64 | 20.34 | 168.81 | 13.01 | 327.70 | 0.3968 | 1025.0 | 784.2 | |
| 0.00 | 1.11 | 0.00 | 0.60 | 20.15 | 168.50 | 12.71 | 328.03 | 0.3917 | 864.0 | 646.8 | |
| 0.00 | 1.71 | 0.00 | 0.92 | 20.62 | 168.44 | 12.65 | 328.81 | 0.3975 | 783.0 | 559.4 | |
| 1.11 | 5.98 | 0.59 | 3.20 | 19.43 | 168.25 | 12.46 | 327.48 | 0.3800 | 1151.5 | 860.7 | |
| 0.00 | 7.94 | 0.00 | 4.27 | 20.56 | 168.08 | 12.29 | 329.45 | 0.3937 | 562.0 | 743.8 | |
| 2.82 | 7.77 | 1.50 | 4.13 | 18.91 | 167.60 | 11.81 | 328.03 | 0.3673 | 1058.7 | 890.2 | |
| 7.26 | 12.38 | 3.87 | 6.60 | 19.41 | 167.35 | 11.56 | 329.32 | 0.3719 | 1045.7 | 493.1 | |
| 0.00 | 1.62 | 0.00 | 0.87 | 19.78 | 167.06 | 11.26 | 330.48 | 0.3747 | 1039.0 | 815.5 | |
| 0.51 | 1.28 | 0.27 | 0.69 | 20.19 | 166.99 | 11.20 | 331.19 | 0.3798 | 952.7 | 824.2 | |
| 0.00 | 1.20 | 0.00 | 0.64 | 19.97 | 166.97 | 11.18 | 330.92 | 0.3767 | 763.0 | 605.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
