SDO HMI 2011-12-01 22:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 25.36 | 147.30 | 19.96 | 116.53 | 19.03 | 104.71 | -48.87 | 65.99 | 0.7817 | -655.5 | -246.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-12-01 22:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.11 | 0.00 | 0.90 | 23.65 | 105.12 | -48.46 | 60.22 | 0.7922 | -584.0 | -551.5 | |
| 0.00 | 1.45 | 0.00 | 1.22 | 24.67 | 103.44 | -50.15 | 59.63 | 0.8109 | -605.0 | -472.2 | |
| 0.00 | 0.77 | 0.00 | 0.67 | 25.67 | 102.44 | -51.14 | 58.81 | 0.8226 | -581.0 | -462.3 | |
| 25.36 | 136.81 | 19.96 | 107.71 | 18.93 | 104.90 | -48.68 | 66.06 | 0.7795 | -943.9 | -275.2 | |
| 0.00 | 0.85 | 0.00 | 0.70 | 21.15 | 103.67 | -49.92 | 63.74 | 0.7980 | -355.0 | -386.5 | |
| 0.00 | 1.37 | 0.00 | 1.14 | 22.13 | 103.15 | -50.43 | 62.73 | 0.8056 | 539.0 | 510.5 | |
| 0.00 | 0.85 | 0.00 | 0.71 | 21.02 | 103.18 | -50.40 | 64.05 | 0.8022 | 485.0 | 383.1 | |
| 0.00 | 1.11 | 0.00 | 0.94 | 18.18 | 101.42 | -52.16 | 67.98 | 0.8116 | 318.0 | 382.3 | |
| 0.00 | 2.13 | 0.00 | 1.81 | 15.43 | 100.62 | -52.96 | 71.49 | 0.8136 | 122.0 | 263.2 | |
| 0.00 | 0.85 | 0.00 | 0.73 | 13.98 | 99.90 | -53.68 | 73.39 | 0.8181 | 519.0 | 491.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
