SDO HMI 2011-12-03 07:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 47.15 | 226.80 | 31.04 | 148.01 | 19.10 | 172.16 | 36.68 | 299.61 | 0.6506 | -276.3 | -48.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-12-03 07:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.02 | 0.00 | 0.71 | 20.67 | 176.08 | 40.60 | 299.55 | 0.7023 | -613.0 | -455.8 | |
| 22.46 | 114.77 | 15.08 | 77.19 | 18.71 | 174.66 | 39.19 | 297.58 | 0.6776 | -999.8 | -224.4 | |
| 0.00 | 0.94 | 0.00 | 0.63 | 19.43 | 174.75 | 39.27 | 298.53 | 0.6818 | -105.0 | -91.8 | |
| 7.09 | -2.00 | 4.74 | -2.00 | 19.05 | 174.24 | 38.76 | 298.28 | 0.6743 | -875.6 | 999999 | |
| 3.16 | 3.84 | 2.10 | 2.55 | 18.62 | 173.92 | 38.44 | 297.83 | 0.6686 | -849.6 | -815.6 | |
| 0.00 | 2.05 | 0.00 | 1.36 | 19.34 | 173.51 | 38.04 | 299.05 | 0.6674 | -825.0 | -641.0 | |
| 0.60 | 3.33 | 0.39 | 2.18 | 18.16 | 173.00 | 37.53 | 297.66 | 0.6558 | -811.0 | -724.4 | |
| 0.00 | 1.54 | 0.00 | 1.01 | 18.69 | 172.90 | 37.43 | 298.46 | 0.6572 | -682.0 | -619.8 | |
| 0.00 | 3.50 | 0.00 | 2.28 | 18.35 | 172.74 | 37.26 | 298.07 | 0.6536 | -930.0 | -851.3 | |
| 2.31 | 3.84 | 1.51 | 2.52 | 19.03 | 172.76 | 37.28 | 299.03 | 0.6572 | -672.3 | -556.8 | |
| 0.00 | 0.94 | 0.00 | 0.61 | 18.53 | 172.59 | 37.11 | 298.41 | 0.6528 | -686.0 | -631.4 | |
| 0.00 | 0.77 | 0.00 | 0.50 | 19.53 | 172.58 | 37.10 | 299.83 | 0.6577 | -718.0 | -593.7 | |
| 0.00 | 3.33 | 0.00 | 2.16 | 18.69 | 172.12 | 36.65 | 298.90 | 0.6481 | -833.0 | -703.4 | |
| 0.00 | 1.37 | 0.00 | 0.88 | 18.44 | 171.98 | 36.51 | 298.62 | 0.6452 | -756.0 | -630.4 | |
| 0.00 | 1.28 | 0.00 | 0.82 | 18.95 | 170.91 | 35.43 | 299.97 | 0.6353 | 507.0 | 309.2 | |
| 0.00 | 1.54 | 0.00 | 0.96 | 17.90 | 169.60 | 34.12 | 299.22 | 0.6140 | 899.0 | 725.3 | |
| 0.00 | 1.02 | 0.00 | 0.65 | 18.83 | 169.81 | 34.34 | 300.47 | 0.6217 | 657.0 | 502.4 | |
| 3.33 | 18.79 | 2.09 | 11.78 | 18.33 | 169.47 | 33.99 | 299.95 | 0.6148 | -644.7 | 93.1 | |
| 0.00 | 0.77 | 0.00 | 0.49 | 20.74 | 169.98 | 34.50 | 303.12 | 0.6348 | 330.0 | 262.6 | |
| 1.62 | 6.49 | 1.03 | 4.13 | 20.74 | 169.71 | 34.24 | 303.30 | 0.6318 | 590.5 | 564.5 | |
| 0.00 | 1.02 | 0.00 | 0.65 | 20.08 | 169.43 | 33.95 | 302.54 | 0.6246 | 676.0 | 501.5 | |
| 0.00 | 5.89 | 0.00 | 3.68 | 18.80 | 169.05 | 33.57 | 300.92 | 0.6125 | -421.0 | -118.8 | |
| 0.00 | 1.20 | 0.00 | 0.76 | 20.74 | 169.52 | 34.04 | 303.43 | 0.6296 | 634.0 | 482.6 | |
| 0.77 | 9.56 | 0.49 | 6.05 | 20.52 | 169.12 | 33.65 | 303.39 | 0.6237 | 890.8 | 720.4 | |
| 0.00 | 3.07 | 0.00 | 1.95 | 21.00 | 169.09 | 33.61 | 304.08 | 0.6263 | 396.0 | 313.9 | |
| 0.00 | 1.02 | 0.00 | 0.65 | 20.62 | 168.80 | 33.33 | 303.74 | 0.6207 | 764.0 | 589.8 | |
| 2.48 | 4.70 | 1.56 | 2.97 | 20.93 | 168.84 | 33.37 | 304.17 | 0.6232 | 746.4 | 720.3 | |
| 0.00 | 2.13 | 0.00 | 1.35 | 21.22 | 168.69 | 33.21 | 304.68 | 0.6233 | 505.0 | 332.6 | |
| 0.00 | 3.42 | 0.00 | 2.15 | 20.97 | 168.47 | 33.00 | 304.47 | 0.6192 | 832.0 | 749.9 | |
| 0.60 | 4.61 | 0.37 | 2.86 | 19.49 | 167.97 | 32.50 | 302.68 | 0.6040 | 761.3 | 649.1 | |
| 1.62 | -30.00 | 1.00 | -30.00 | 19.59 | 167.81 | 32.33 | 302.94 | 0.6027 | 822.7 | 999999 | |
| 0.00 | 1.71 | 0.00 | 1.07 | 20.72 | 167.81 | 32.34 | 304.59 | 0.6100 | 386.0 | 455.2 | |
| 0.00 | 1.20 | 0.00 | 0.74 | 19.78 | 167.33 | 31.86 | 303.57 | 0.5983 | 194.0 | 169.9 | |
| 0.00 | 1.71 | 0.00 | 1.06 | 20.00 | 167.34 | 31.87 | 303.88 | 0.5999 | 757.0 | 526.5 | |
| 0.00 | 1.20 | 0.00 | 0.74 | 20.03 | 167.13 | 31.65 | 304.09 | 0.5976 | 821.0 | 611.4 | |
| 1.11 | 4.44 | 0.68 | 2.73 | 20.32 | 166.68 | 31.20 | 304.85 | 0.5943 | 916.1 | 671.5 | |
| 0.00 | 1.62 | 0.00 | 0.99 | 20.00 | 166.42 | 30.95 | 304.58 | 0.5892 | 765.0 | 587.1 | |
| 0.00 | 1.20 | 0.00 | 0.73 | 20.69 | 166.43 | 30.95 | 305.60 | 0.5940 | 617.0 | 517.1 | |
| 0.00 | 1.02 | 0.00 | 0.63 | 20.70 | 166.24 | 30.77 | 305.75 | 0.5919 | 593.0 | 403.9 | |
| 0.00 | 1.02 | 0.00 | 0.60 | 17.62 | 162.40 | 26.92 | 304.21 | 0.5239 | -642.0 | -535.2 | |
| 0.00 | 1.71 | 0.00 | 0.99 | 17.87 | 162.16 | 26.68 | 304.84 | 0.5229 | -749.0 | -545.8 | |
| 0.00 | 0.94 | 0.00 | 0.53 | 16.83 | 160.08 | 24.60 | 305.09 | 0.4890 | -582.0 | -465.3 | |
| 0.00 | 1.28 | 0.00 | 0.72 | 16.16 | 158.71 | 23.23 | 305.33 | 0.4663 | -846.0 | -646.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
