SDO HMI 2011-12-04 02:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 269.30 | 1421.65 | 151.97 | 800.33 | -21.88 | 107.43 | -17.60 | 143.91 | 0.4768 | 11.5 | 61.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-12-04 02:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.28 | 0.00 | 0.66 | -16.93 | 125.41 | 0.39 | 181.24 | 0.3017 | 718.0 | 616.1 | |
| 0.00 | 0.94 | 0.00 | 0.49 | -17.09 | 122.39 | -2.64 | 171.73 | 0.3074 | -829.0 | -626.4 | |
| 0.00 | 1.28 | 0.00 | 0.66 | -14.53 | 119.70 | -5.33 | 160.93 | 0.2764 | -948.0 | -777.5 | |
| 0.00 | 0.77 | 0.00 | 0.40 | -14.02 | 118.36 | -6.66 | 155.86 | 0.2766 | -897.0 | -759.4 | |
| 0.00 | 1.02 | 0.00 | 0.54 | -16.81 | 118.24 | -6.79 | 159.23 | 0.3204 | -999.0 | -851.9 | |
| 0.00 | 1.11 | 0.00 | 0.58 | -17.71 | 117.36 | -7.66 | 157.92 | 0.3395 | -971.0 | -812.5 | |
| 0.00 | 1.37 | 0.00 | 0.72 | -18.06 | 116.15 | -8.87 | 155.30 | 0.3525 | -803.0 | -649.2 | |
| 0.00 | 0.94 | 0.00 | 0.50 | -18.34 | 116.08 | -8.95 | 155.46 | 0.3572 | -743.0 | -602.2 | |
| 0.77 | 91.09 | 0.41 | 48.85 | -17.45 | 111.67 | -13.36 | 144.46 | 0.3808 | 1196.2 | 505.7 | |
| 16.13 | -9.00 | 8.66 | -9.00 | -17.54 | 111.28 | -13.75 | 143.85 | 0.3857 | 1304.2 | 999999 | |
| 38.16 | 694.80 | 21.22 | 388.85 | -22.63 | 110.72 | -14.31 | 149.87 | 0.4565 | 1463.5 | 414.5 | |
| 19.46 | -11.00 | 10.87 | -11.00 | -23.18 | 110.62 | -14.40 | 150.36 | 0.4644 | 1147.7 | 999999 | |
| 0.00 | 2.48 | 0.00 | 1.35 | -19.54 | 110.56 | -14.46 | 145.55 | 0.4179 | 832.0 | 629.8 | |
| 0.00 | 1.37 | 0.00 | 0.74 | -17.76 | 110.72 | -14.31 | 143.12 | 0.3939 | 7.0 | 38.9 | |
| 0.00 | 1.28 | 0.00 | 0.73 | -24.57 | 109.96 | -15.07 | 150.87 | 0.4876 | -732.0 | -529.6 | |
| 2.05 | -11.00 | 1.15 | -11.00 | -23.08 | 110.07 | -14.96 | 149.33 | 0.4675 | 932.4 | 999999 | |
| 0.00 | 1.28 | 0.00 | 0.73 | -24.84 | 109.86 | -15.17 | 150.99 | 0.4917 | -649.0 | -432.0 | |
| 1.54 | -11.00 | 0.86 | -11.00 | -23.27 | 109.91 | -15.11 | 149.31 | 0.4712 | 700.5 | 999999 | |
| 1.02 | -11.00 | 0.57 | -11.00 | -22.95 | 109.88 | -15.14 | 148.88 | 0.4673 | 1056.2 | 999999 | |
| 9.56 | -11.00 | 5.34 | -11.00 | -22.73 | 109.81 | -15.22 | 148.48 | 0.4650 | 1115.8 | 999999 | |
| 1.62 | -11.00 | 0.90 | -11.00 | -22.41 | 109.81 | -15.21 | 148.09 | 0.4609 | 962.6 | 999999 | |
| 3.76 | -11.00 | 2.11 | -11.00 | -23.18 | 109.49 | -15.54 | 148.51 | 0.4733 | 753.3 | 999999 | |
| 5.04 | -11.00 | 2.81 | -11.00 | -22.28 | 109.53 | -15.50 | 147.46 | 0.4616 | 957.5 | 999999 | |
| 0.51 | -11.00 | 0.29 | -11.00 | -22.82 | 109.40 | -15.63 | 147.93 | 0.4696 | 762.0 | 999999 | |
| 0.00 | 2.90 | 0.00 | 1.65 | -24.81 | 109.15 | -15.87 | 149.87 | 0.4966 | 646.0 | 404.6 | |
| 5.89 | -11.00 | 3.32 | -11.00 | -23.50 | 109.22 | -15.81 | 148.47 | 0.4797 | 906.2 | 999999 | |
| 0.00 | 1.20 | 0.00 | 0.64 | -16.89 | 109.64 | -15.39 | 139.69 | 0.3942 | 853.0 | 792.5 | |
| 7.09 | -11.00 | 3.97 | -11.00 | -22.60 | 109.03 | -16.00 | 147.06 | 0.4699 | 871.5 | 999999 | |
| 1.88 | -11.00 | 1.04 | -11.00 | -21.19 | 109.19 | -15.84 | 145.48 | 0.4509 | -755.2 | 999999 | |
| 0.00 | 0.94 | 0.00 | 0.54 | -25.33 | 108.37 | -16.66 | 149.28 | 0.5093 | 561.0 | 461.5 | |
| 11.87 | -11.00 | 6.69 | -11.00 | -23.02 | 108.47 | -16.55 | 146.72 | 0.4798 | 1060.0 | 999999 | |
| 0.00 | 1.62 | 0.00 | 0.89 | -18.58 | 108.91 | -16.12 | 141.18 | 0.4217 | 776.0 | 633.6 | |
| 2.39 | 21.85 | 1.33 | 12.18 | -21.07 | 108.38 | -16.65 | 144.00 | 0.4567 | 753.6 | -236.4 | |
| 3.16 | -11.00 | 1.79 | -11.00 | -23.05 | 108.03 | -16.99 | 146.08 | 0.4839 | 835.4 | 999999 | |
| 0.00 | 1.37 | 0.00 | 0.77 | -21.99 | 108.07 | -16.96 | 144.76 | 0.4707 | 759.0 | 526.6 | |
| 0.00 | 1.11 | 0.00 | 0.62 | -21.42 | 107.87 | -17.15 | 143.69 | 0.4656 | -911.0 | -770.5 | |
| 2.90 | -11.00 | 1.64 | -11.00 | -23.09 | 107.62 | -17.40 | 145.51 | 0.4878 | 771.9 | 999999 | |
| 0.00 | 0.85 | 0.00 | 0.49 | -24.03 | 107.46 | -17.56 | 146.44 | 0.5006 | 566.0 | 389.2 | |
| 1.71 | 8.71 | 0.96 | 4.88 | -21.64 | 107.74 | -17.28 | 143.80 | 0.4694 | -637.8 | -261.0 | |
| 0.00 | 0.94 | 0.00 | 0.52 | -18.95 | 107.99 | -17.04 | 140.26 | 0.4353 | -785.0 | -525.0 | |
| 9.73 | -11.00 | 5.54 | -11.00 | -23.32 | 107.22 | -17.80 | 145.20 | 0.4941 | 807.1 | 999999 | |
| 1.37 | 172.53 | 0.77 | 97.26 | -22.03 | 107.19 | -17.83 | 143.48 | 0.4790 | 923.8 | -268.5 | |
| 1.20 | -11.00 | 0.68 | -11.00 | -22.61 | 106.95 | -18.08 | 143.89 | 0.4881 | -590.1 | 999999 | |
| 0.00 | 1.88 | 0.00 | 1.07 | -22.90 | 106.91 | -18.12 | 144.21 | 0.4919 | 164.0 | 175.5 | |
| 0.00 | 1.28 | 0.00 | 0.71 | -19.27 | 107.33 | -17.70 | 139.71 | 0.4456 | -975.0 | -791.9 | |
| 2.99 | -11.00 | 1.71 | -11.00 | -23.67 | 106.73 | -18.29 | 144.94 | 0.5026 | 544.5 | 999999 | |
| 0.00 | 0.85 | 0.00 | 0.48 | -20.56 | 107.15 | -17.88 | 141.37 | 0.4624 | -836.0 | -727.4 | |
| 0.00 | 1.11 | 0.00 | 0.62 | -19.55 | 107.10 | -17.93 | 139.80 | 0.4512 | -836.0 | -662.0 | |
| 1.88 | -42.00 | 1.06 | -42.00 | -21.68 | 106.77 | -18.25 | 142.38 | 0.4789 | 583.7 | 999999 | |
| 0.00 | 0.85 | 0.00 | 0.49 | -24.46 | 106.17 | -18.86 | 145.12 | 0.5166 | 399.0 | 417.6 | |
| 4.87 | -42.00 | 2.73 | -42.00 | -21.11 | 106.55 | -18.48 | 141.25 | 0.4744 | -1190.1 | 999999 | |
| 2.30 | 11.10 | 1.33 | 6.39 | -24.00 | 106.10 | -18.92 | 144.47 | 0.5119 | 722.3 | 433.2 | |
| 0.00 | 2.05 | 0.00 | 1.14 | -19.40 | 106.52 | -18.50 | 138.69 | 0.4553 | -997.0 | -807.7 | |
| 3.67 | -42.00 | 2.06 | -42.00 | -20.66 | 106.34 | -18.69 | 140.30 | 0.4714 | 770.1 | 999999 | |
| 0.00 | 0.68 | 0.00 | 0.40 | -24.52 | 105.75 | -19.28 | 144.63 | 0.5210 | 600.0 | 488.4 | |
| 2.65 | -42.00 | 1.49 | -42.00 | -20.98 | 106.23 | -18.80 | 140.61 | 0.4761 | -1342.0 | 999999 | |
| 0.00 | 3.50 | 0.00 | 1.99 | -22.48 | 105.89 | -19.14 | 142.21 | 0.4964 | -1080.0 | -844.5 | |
| 1.28 | -42.00 | 0.72 | -42.00 | -21.01 | 105.96 | -19.07 | 140.26 | 0.4791 | -950.8 | 999999 | |
| 0.60 | 2.48 | 0.34 | 1.42 | -23.29 | 105.63 | -19.40 | 142.92 | 0.5079 | -921.6 | -583.9 | |
| 1.96 | -42.00 | 1.11 | -42.00 | -21.04 | 105.78 | -19.24 | 140.07 | 0.4812 | -953.5 | 999999 | |
| 0.00 | 2.05 | 0.00 | 1.14 | -18.68 | 106.08 | -18.95 | 136.90 | 0.4521 | -728.0 | -535.5 | |
| 0.00 | 1.62 | 0.00 | 0.94 | -24.66 | 105.17 | -19.85 | 144.03 | 0.5276 | 737.0 | 474.3 | |
| 0.00 | 1.20 | 0.00 | 0.69 | -23.23 | 105.40 | -19.62 | 142.52 | 0.5093 | -739.0 | -587.6 | |
| 0.00 | 5.21 | 0.00 | 3.00 | -23.42 | 105.27 | -19.76 | 142.59 | 0.5127 | -609.0 | -425.8 | |
| 3.93 | -42.00 | 2.22 | -42.00 | -20.86 | 105.37 | -19.65 | 139.22 | 0.4832 | -1073.9 | 999999 | |
| 9.65 | -42.00 | 5.47 | -42.00 | -21.17 | 105.26 | -19.76 | 139.52 | 0.4878 | -1035.5 | 999999 | |
| 0.00 | 0.94 | 0.00 | 0.54 | -22.65 | 105.05 | -19.98 | 141.27 | 0.5061 | -649.0 | -454.5 | |
| 0.00 | 1.20 | 0.00 | 0.70 | -24.20 | 104.73 | -20.30 | 142.88 | 0.5264 | -644.0 | -513.1 | |
| 0.00 | 5.63 | 0.00 | 3.21 | -21.65 | 104.96 | -20.07 | 139.79 | 0.4960 | -809.0 | -705.7 | |
| 0.00 | 0.85 | 0.00 | 0.51 | -26.07 | 104.22 | -20.80 | 144.51 | 0.5517 | 558.0 | 433.6 | |
| 0.00 | 2.65 | 0.00 | 1.53 | -23.13 | 104.63 | -20.40 | 141.36 | 0.5154 | -863.0 | -734.3 | |
| 0.00 | 1.45 | 0.00 | 0.82 | -21.18 | 104.86 | -20.17 | 138.97 | 0.4918 | -579.0 | -548.4 | |
| 0.00 | 2.73 | 0.00 | 1.54 | -20.10 | 104.94 | -20.09 | 137.50 | 0.4794 | -957.0 | -812.6 | |
| 0.00 | 1.71 | 0.00 | 0.98 | -22.23 | 104.36 | -20.67 | 139.80 | 0.5082 | -558.0 | -643.8 | |
| 2.65 | 3.50 | 1.51 | 2.00 | -21.34 | 104.46 | -20.57 | 138.67 | 0.4975 | -978.4 | -835.0 | |
| 0.00 | 1.88 | 0.00 | 1.08 | -22.46 | 104.26 | -20.77 | 139.97 | 0.5116 | -932.0 | -853.7 | |
| 1.71 | 20.83 | 0.99 | 12.08 | -23.26 | 103.99 | -21.04 | 140.71 | 0.5229 | -1080.2 | -664.8 | |
| 0.51 | 1.79 | 0.29 | 1.01 | -19.85 | 104.47 | -20.56 | 136.48 | 0.4816 | -1078.3 | -925.2 | |
| 0.00 | 1.11 | 0.00 | 0.63 | -19.63 | 104.50 | -20.53 | 136.18 | 0.4790 | -912.0 | -777.6 | |
| 1.28 | 7.26 | 0.73 | 4.15 | -21.50 | 104.20 | -20.83 | 138.56 | 0.5019 | -915.7 | -912.2 | |
| 0.00 | 1.37 | 0.00 | 0.78 | -20.54 | 104.34 | -20.69 | 137.35 | 0.4903 | -766.0 | -625.5 | |
| 4.44 | -77.00 | 2.57 | -77.00 | -23.04 | 103.92 | -21.10 | 140.32 | 0.5211 | -1104.7 | 999999 | |
| 0.00 | 1.54 | 0.00 | 0.89 | -22.75 | 103.93 | -21.09 | 139.95 | 0.5178 | -812.0 | -560.1 | |
| 1.54 | -77.00 | 0.89 | -77.00 | -23.36 | 103.73 | -21.30 | 140.51 | 0.5264 | -434.1 | 999999 | |
| 0.43 | 3.84 | 0.24 | 2.17 | -19.50 | 104.28 | -20.74 | 135.70 | 0.4801 | -962.8 | -746.8 | |
| 0.00 | 1.71 | 0.00 | 1.00 | -23.95 | 103.59 | -21.43 | 141.10 | 0.5339 | -753.0 | -552.8 | |
| 0.00 | 1.71 | 0.00 | 0.97 | -19.78 | 104.21 | -20.82 | 136.04 | 0.4838 | -1057.0 | -897.7 | |
| 0.00 | 0.85 | 0.00 | 0.48 | -19.09 | 104.13 | -20.89 | 134.87 | 0.4775 | -822.0 | -650.4 | |
| 0.94 | 4.35 | 0.55 | 2.53 | -23.30 | 103.43 | -21.60 | 140.05 | 0.5286 | -579.0 | -588.1 | |
| 1.37 | 285.21 | 0.79 | 164.21 | -21.85 | 103.63 | -21.39 | 138.33 | 0.5113 | -819.3 | -446.4 | |
| 0.85 | -90.00 | 0.49 | -90.00 | -21.50 | 103.45 | -21.58 | 137.60 | 0.5095 | -1087.8 | 999999 | |
| 0.00 | 1.37 | 0.00 | 0.80 | -23.04 | 103.13 | -21.90 | 139.33 | 0.5288 | -687.0 | -605.1 | |
| 2.05 | -90.00 | 1.18 | -90.00 | -21.56 | 103.23 | -21.79 | 137.42 | 0.5123 | -970.8 | 999999 | |
| 1.37 | -90.00 | 0.78 | -90.00 | -20.77 | 103.29 | -21.74 | 136.33 | 0.5036 | -1002.5 | 999999 | |
| 1.37 | -90.00 | 0.79 | -90.00 | -21.44 | 103.12 | -21.91 | 137.09 | 0.5122 | -1143.9 | 999999 | |
| 16.99 | -90.00 | 9.88 | -90.00 | -22.59 | 102.89 | -22.13 | 138.43 | 0.5264 | -852.7 | 999999 | |
| 1.62 | -90.00 | 0.94 | -90.00 | -22.05 | 102.81 | -22.21 | 137.58 | 0.5216 | -745.1 | 999999 | |
| 25.87 | -90.00 | 14.90 | -90.00 | -21.28 | 102.90 | -22.12 | 136.60 | 0.5128 | -1125.8 | 999999 | |
| 15.96 | -90.00 | 9.13 | -90.00 | -20.26 | 102.92 | -22.10 | 135.13 | 0.5024 | -1186.7 | 999999 | |
| 2.05 | -90.00 | 1.18 | -90.00 | -21.28 | 102.63 | -22.40 | 136.26 | 0.5157 | -665.3 | 999999 | |
| 0.60 | -90.00 | 0.34 | -90.00 | -20.39 | 102.43 | -22.60 | 134.71 | 0.5090 | -261.4 | 999999 | |
| 0.00 | 0.77 | 0.00 | 0.44 | -20.02 | 101.90 | -23.12 | 133.52 | 0.5109 | -682.0 | -483.7 | |
| 1.11 | 7.17 | 0.64 | 4.12 | -19.51 | 101.88 | -23.15 | 132.72 | 0.5064 | -953.2 | -677.1 | |
| 0.00 | 1.37 | 0.00 | 0.79 | -20.59 | 101.57 | -23.45 | 133.99 | 0.5200 | -638.0 | -525.3 | |
| 0.00 | 1.54 | 0.00 | 0.91 | -20.66 | 99.37 | -25.66 | 131.69 | 0.5446 | -590.0 | -419.4 | |
| 0.00 | 1.02 | 0.00 | 0.61 | -20.48 | 97.64 | -27.39 | 129.69 | 0.5623 | -618.0 | -435.1 | |
| 0.00 | 0.85 | 0.00 | 0.52 | -21.75 | 97.20 | -27.83 | 131.11 | 0.5777 | -616.0 | -531.5 | |
| 0.00 | 1.02 | 0.00 | 0.62 | -20.10 | 96.82 | -28.21 | 128.38 | 0.5684 | -645.0 | -507.5 | |
| 0.00 | 1.54 | 0.00 | 0.99 | -24.98 | 93.54 | -31.48 | 132.22 | 0.6415 | -541.0 | -438.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
