SDO HMI 2011-12-04 09:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 3.76 | 9.48 | 2.77 | 7.00 | -19.58 | 76.87 | -44.34 | 117.30 | 0.7435 | -2.6 | 146.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-12-04 09:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.77 | 0.00 | 0.54 | -17.84 | 79.36 | -41.85 | 116.20 | 0.7101 | 580.0 | 434.4 | |
| 0.00 | 1.11 | 0.00 | 0.78 | -17.75 | 79.18 | -42.03 | 115.99 | 0.7118 | 723.0 | 649.3 | |
| 0.00 | 0.77 | 0.00 | 0.55 | -17.88 | 77.91 | -43.30 | 115.62 | 0.7262 | 468.0 | 377.6 | |
| 0.00 | 1.54 | 0.00 | 1.23 | -25.41 | 74.59 | -46.62 | 123.49 | 0.7895 | -325.0 | -276.4 | |
| 0.00 | 0.77 | 0.00 | 0.56 | -17.70 | 77.41 | -43.80 | 115.17 | 0.7309 | 435.0 | 465.3 | |
| 3.76 | 4.52 | 2.77 | 3.34 | -18.73 | 76.51 | -44.70 | 116.14 | 0.7444 | -686.3 | -432.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
