SDO HMI 2011-12-04 17:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 103.80 | 516.45 | 53.65 | 265.64 | 7.78 | 129.97 | 13.16 | 301.57 | 0.2641 | -47.4 | 99.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-12-04 17:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.19 | 0.00 | 0.64 | 7.69 | 137.31 | 20.50 | 289.96 | 0.3709 | -631.0 | -551.7 | |
| 0.00 | 1.11 | 0.00 | 0.59 | 7.57 | 137.24 | 20.43 | 289.71 | 0.3692 | -817.0 | -679.0 | |
| 2.30 | 3.50 | 1.22 | 1.85 | 7.93 | 136.02 | 19.21 | 291.77 | 0.3525 | 750.9 | 594.6 | |
| 26.10 | 130.42 | 13.75 | 68.70 | 6.65 | 135.75 | 18.94 | 288.53 | 0.3415 | -1267.9 | -386.8 | |
| 0.34 | -4.00 | 0.18 | -4.00 | 6.38 | 135.55 | 18.74 | 287.94 | 0.3371 | -981.0 | 999999 | |
| 4.09 | -4.00 | 2.14 | -4.00 | 6.74 | 134.78 | 17.97 | 289.68 | 0.3268 | -971.5 | 999999 | |
| 0.00 | 1.02 | 0.00 | 0.53 | 5.67 | 134.06 | 17.25 | 287.14 | 0.3101 | -669.0 | -504.8 | |
| 17.32 | 33.69 | 9.03 | 17.58 | 6.57 | 134.02 | 17.21 | 289.91 | 0.3141 | -1036.4 | -770.6 | |
| 1.71 | -8.00 | 0.89 | -8.00 | 6.74 | 133.72 | 16.91 | 290.77 | 0.3103 | -1001.7 | 999999 | |
| 0.00 | 0.85 | 0.00 | 0.44 | 6.39 | 133.61 | 16.80 | 289.79 | 0.3067 | -647.0 | -483.2 | |
| 1.54 | 7.42 | 0.80 | 3.86 | 7.25 | 133.58 | 16.77 | 292.46 | 0.3111 | -947.0 | -775.3 | |
| 4.09 | 10.58 | 2.13 | 5.49 | 6.54 | 133.37 | 16.56 | 290.51 | 0.3037 | -1139.9 | -973.4 | |
| 0.00 | 2.13 | 0.00 | 1.10 | 4.88 | 132.98 | 16.17 | 285.53 | 0.2893 | -769.0 | -659.2 | |
| 0.00 | 3.92 | 0.00 | 2.03 | 5.32 | 132.90 | 16.09 | 287.09 | 0.2900 | -1136.0 | -896.5 | |
| 0.00 | 1.36 | 0.00 | 0.71 | 8.00 | 131.81 | 15.00 | 297.10 | 0.2893 | -829.0 | -613.4 | |
| 0.00 | 1.88 | 0.00 | 0.97 | 7.49 | 131.46 | 14.65 | 296.03 | 0.2803 | -480.0 | -519.3 | |
| 0.00 | 2.90 | 0.00 | 1.49 | 7.64 | 130.60 | 13.79 | 297.89 | 0.2685 | 967.0 | 736.6 | |
| 0.00 | 2.81 | 0.00 | 1.46 | 10.78 | 130.57 | 13.76 | 307.47 | 0.2958 | -911.0 | -682.9 | |
| 0.00 | 1.45 | 0.00 | 0.75 | 10.60 | 130.41 | 13.60 | 307.30 | 0.2918 | -875.0 | -763.1 | |
| 0.00 | 1.11 | 0.00 | 0.57 | 10.63 | 130.22 | 13.41 | 307.75 | 0.2897 | -1021.0 | -830.2 | |
| 0.00 | 1.96 | 0.00 | 1.00 | 6.67 | 128.10 | 11.29 | 299.04 | 0.2235 | -864.0 | -649.4 | |
| 0.00 | 1.71 | 0.00 | 0.87 | 10.69 | 127.95 | 11.14 | 313.08 | 0.2612 | 864.0 | 692.8 | |
| 0.00 | 1.28 | 0.00 | 0.65 | 7.08 | 127.60 | 10.79 | 301.81 | 0.2196 | -1059.0 | -845.6 | |
| 0.00 | 1.28 | 0.00 | 0.65 | 10.04 | 127.35 | 10.54 | 312.71 | 0.2462 | 980.0 | 744.9 | |
| 1.36 | 295.04 | 0.69 | 149.75 | 8.93 | 127.28 | 10.47 | 309.34 | 0.2332 | 783.1 | 435.6 | |
| 0.00 | 1.36 | 0.00 | 0.70 | 10.19 | 127.20 | 10.39 | 313.56 | 0.2461 | 1192.0 | 1057.5 | |
| 41.54 | -25.00 | 21.09 | -25.00 | 8.54 | 126.63 | 9.82 | 309.78 | 0.2206 | 1402.6 | 999999 | |
| 0.00 | 2.81 | 0.00 | 1.42 | 7.35 | 126.61 | 9.80 | 305.39 | 0.2079 | 954.0 | 772.8 | |
| 3.41 | -25.00 | 1.73 | -25.00 | 7.95 | 126.04 | 9.23 | 309.31 | 0.2064 | 1321.6 | 999999 | |
| 0.00 | 1.45 | 0.00 | 0.73 | 6.91 | 123.29 | 6.48 | 315.02 | 0.1592 | 1056.0 | 813.6 | |
| 0.00 | 0.94 | 0.00 | 0.47 | 6.88 | 123.08 | 6.27 | 315.82 | 0.1563 | 1008.0 | 858.5 | |
| 0.00 | 1.28 | 0.00 | 0.64 | 6.73 | 122.87 | 6.06 | 316.12 | 0.1520 | 881.0 | 723.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
