SDO HMI 2011-12-04 20:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 242.61 | 1517.40 | 131.31 | 821.18 | -21.92 | 107.54 | -7.61 | 162.29 | 0.4050 | 7.5 | 97.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-12-04 20:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.94 | 0.00 | 0.49 | -18.53 | 120.31 | 5.16 | 194.69 | 0.3379 | -737.0 | -480.3 | |
| 0.00 | 0.85 | 0.00 | 0.44 | -14.12 | 119.77 | 4.62 | 197.23 | 0.2647 | -933.0 | -709.5 | |
| 0.00 | 0.85 | 0.00 | 0.45 | -17.75 | 117.90 | 2.74 | 188.30 | 0.3172 | -953.0 | -789.9 | |
| 0.00 | 1.45 | 0.00 | 0.76 | -18.03 | 117.62 | 2.47 | 187.36 | 0.3212 | -793.0 | -670.8 | |
| 0.00 | 1.28 | 0.00 | 0.67 | -18.19 | 117.06 | 1.91 | 185.66 | 0.3227 | -886.0 | -644.8 | |
| 0.00 | 1.36 | 0.00 | 0.71 | -17.84 | 117.03 | 1.88 | 185.67 | 0.3170 | -743.0 | -539.8 | |
| 0.00 | 1.28 | 0.00 | 0.67 | -18.31 | 116.41 | 1.26 | 183.71 | 0.3239 | -966.0 | -776.7 | |
| 0.00 | 0.85 | 0.00 | 0.44 | -17.41 | 112.81 | -2.34 | 172.77 | 0.3107 | 726.0 | 572.7 | |
| 0.00 | 1.54 | 0.00 | 0.85 | -26.00 | 110.99 | -4.16 | 171.67 | 0.4522 | 658.0 | 506.8 | |
| 19.62 | 72.59 | 10.25 | 37.92 | -17.63 | 111.17 | -3.98 | 167.96 | 0.3189 | 1287.0 | 486.8 | |
| 34.38 | 839.96 | 18.56 | 454.57 | -22.55 | 110.53 | -4.63 | 169.21 | 0.3997 | 1595.0 | 415.3 | |
| 15.95 | -11.00 | 8.65 | -11.00 | -23.07 | 110.35 | -4.80 | 169.07 | 0.4083 | 1294.9 | 999999 | |
| 1.45 | -11.00 | 0.78 | -11.00 | -21.56 | 110.11 | -5.04 | 167.71 | 0.3854 | 1115.1 | 999999 | |
| 0.00 | 1.62 | 0.00 | 0.84 | -15.28 | 110.17 | -4.98 | 162.84 | 0.2852 | 828.0 | 463.6 | |
| 5.97 | -11.00 | 3.24 | -11.00 | -23.07 | 109.86 | -5.29 | 168.01 | 0.4098 | 1139.9 | 999999 | |
| 8.10 | -11.00 | 4.39 | -11.00 | -22.78 | 109.68 | -5.47 | 167.44 | 0.4059 | 1384.6 | 999999 | |
| 3.33 | -11.00 | 1.81 | -11.00 | -23.16 | 109.57 | -5.58 | 167.42 | 0.4123 | 952.2 | 999999 | |
| 2.56 | -11.00 | 1.38 | -11.00 | -22.49 | 109.34 | -5.81 | 166.51 | 0.4027 | 1065.4 | 999999 | |
| 1.02 | -11.00 | 0.56 | -11.00 | -23.49 | 109.26 | -5.89 | 166.95 | 0.4184 | 656.8 | 999999 | |
| 1.28 | -11.00 | 0.70 | -11.00 | -23.26 | 109.24 | -5.91 | 166.77 | 0.4150 | 889.7 | 999999 | |
| 0.68 | -11.00 | 0.37 | -11.00 | -22.97 | 109.22 | -5.93 | 166.55 | 0.4106 | 905.1 | 999999 | |
| 0.85 | -11.00 | 0.46 | -11.00 | -22.39 | 109.18 | -5.97 | 166.10 | 0.4018 | 951.1 | 999999 | |
| 0.00 | 1.11 | 0.00 | 0.61 | -24.72 | 109.01 | -6.14 | 167.14 | 0.4383 | 594.0 | 460.8 | |
| 1.28 | -11.00 | 0.69 | -11.00 | -22.62 | 109.04 | -6.11 | 165.94 | 0.4058 | 966.8 | 999999 | |
| 0.00 | 1.19 | 0.00 | 0.66 | -25.18 | 108.82 | -6.33 | 167.02 | 0.4459 | 739.0 | 642.5 | |
| 0.94 | -11.00 | 0.51 | -11.00 | -23.36 | 108.75 | -6.40 | 165.78 | 0.4184 | 779.4 | 999999 | |
| 15.35 | -11.00 | 8.34 | -11.00 | -22.97 | 108.71 | -6.44 | 165.43 | 0.4126 | 1139.3 | 999999 | |
| 0.00 | 1.88 | 0.00 | 0.98 | -17.38 | 108.81 | -6.34 | 161.01 | 0.3254 | 960.0 | 693.0 | |
| 1.11 | -11.00 | 0.60 | -11.00 | -22.94 | 108.38 | -6.77 | 164.72 | 0.4134 | 1010.8 | 999999 | |
| 3.24 | -11.00 | 1.77 | -11.00 | -23.65 | 108.35 | -6.80 | 165.12 | 0.4244 | 429.3 | 999999 | |
| 1.71 | -11.00 | 0.93 | -11.00 | -23.00 | 108.16 | -7.00 | 164.27 | 0.4154 | 663.2 | 999999 | |
| 0.00 | 1.02 | 0.00 | 0.56 | -23.97 | 107.91 | -7.24 | 164.44 | 0.4312 | -818.0 | -707.1 | |
| 0.00 | 1.11 | 0.00 | 0.59 | -20.80 | 107.98 | -7.17 | 162.15 | 0.3825 | -760.0 | -593.6 | |
| 5.03 | -11.00 | 2.74 | -11.00 | -23.00 | 107.83 | -7.32 | 163.59 | 0.4168 | 665.5 | 999999 | |
| 0.00 | 1.02 | 0.00 | 0.55 | -20.67 | 107.66 | -7.49 | 161.32 | 0.3822 | -857.0 | -633.1 | |
| 1.62 | -11.00 | 0.87 | -11.00 | -21.47 | 107.40 | -7.75 | 161.42 | 0.3956 | -913.7 | 999999 | |
| 0.00 | 2.13 | 0.00 | 1.15 | -22.01 | 107.27 | -7.88 | 161.61 | 0.4045 | 741.0 | 573.1 | |
| 1.71 | 18.94 | 0.93 | 10.35 | -23.33 | 107.03 | -8.12 | 162.18 | 0.4254 | 535.7 | 332.8 | |
| 0.00 | 1.11 | 0.00 | 0.59 | -19.32 | 107.19 | -7.96 | 158.88 | 0.3643 | -890.0 | -686.4 | |
| 0.00 | 3.07 | 0.00 | 1.66 | -22.01 | 106.98 | -8.17 | 160.99 | 0.4060 | 701.0 | 535.4 | |
| 0.00 | 1.88 | 0.00 | 1.00 | -19.66 | 107.11 | -8.04 | 159.05 | 0.3699 | -938.0 | -797.0 | |
| 0.00 | 0.94 | 0.00 | 0.51 | -23.55 | 106.83 | -8.33 | 161.93 | 0.4298 | 546.0 | 366.1 | |
| 0.00 | 2.47 | 0.00 | 1.35 | -22.97 | 106.83 | -8.32 | 161.47 | 0.4212 | 704.0 | 585.6 | |
| 0.00 | 3.41 | 0.00 | 1.84 | -21.66 | 106.78 | -8.37 | 160.23 | 0.4018 | -15.0 | -65.1 | |
| 0.00 | 1.45 | 0.00 | 0.78 | -20.04 | 106.78 | -8.38 | 158.66 | 0.3776 | -666.0 | -612.7 | |
| 0.00 | 0.34 | 0.00 | 0.18 | -19.76 | 106.79 | -8.36 | 158.40 | 0.3733 | -888.0 | -757.0 | |
| 0.00 | 2.73 | 0.00 | 1.50 | -24.04 | 106.47 | -8.68 | 161.61 | 0.4388 | 746.0 | 573.5 | |
| 0.00 | 2.05 | 0.00 | 1.08 | -17.82 | 106.79 | -8.36 | 156.19 | 0.3443 | -868.0 | -638.4 | |
| 0.00 | 0.77 | 0.00 | 0.42 | -21.72 | 106.55 | -8.60 | 159.80 | 0.4040 | -653.0 | -562.1 | |
| 0.00 | 1.54 | 0.00 | 0.81 | -18.13 | 106.68 | -8.47 | 156.30 | 0.3496 | -827.0 | -659.6 | |
| 3.16 | 5.20 | 1.72 | 2.83 | -22.52 | 106.34 | -8.81 | 160.08 | 0.4170 | 716.4 | 244.5 | |
| 5.63 | 146.04 | 3.03 | 78.84 | -21.06 | 106.33 | -8.82 | 158.69 | 0.3953 | -1241.3 | -421.1 | |
| 0.00 | 6.65 | 0.00 | 3.61 | -21.88 | 106.15 | -9.00 | 159.11 | 0.4086 | 122.0 | 88.2 | |
| 8.53 | -52.00 | 4.59 | -52.00 | -20.67 | 106.20 | -8.95 | 158.01 | 0.3905 | 856.5 | 999999 | |
| 0.00 | 2.22 | 0.00 | 1.21 | -22.75 | 106.03 | -9.12 | 159.65 | 0.4220 | 542.0 | 426.7 | |
| 0.00 | 0.94 | 0.00 | 0.50 | -19.41 | 106.08 | -9.07 | 156.37 | 0.3726 | -906.0 | -778.8 | |
| 0.00 | 1.02 | 0.00 | 0.57 | -25.42 | 105.51 | -9.64 | 160.88 | 0.4638 | 711.0 | 600.4 | |
| 0.00 | 1.45 | 0.00 | 0.81 | -25.61 | 105.46 | -9.69 | 160.94 | 0.4669 | 456.0 | 464.0 | |
| 0.00 | 1.62 | 0.00 | 0.90 | -24.99 | 105.44 | -9.71 | 160.42 | 0.4579 | 714.0 | 505.0 | |
| 0.00 | 1.11 | 0.00 | 0.62 | -25.25 | 105.42 | -9.73 | 160.59 | 0.4618 | 696.0 | 518.2 | |
| 2.39 | -52.00 | 1.29 | -52.00 | -21.15 | 105.69 | -9.46 | 157.39 | 0.4006 | -1050.4 | 999999 | |
| 0.51 | -52.00 | 0.28 | -52.00 | -21.25 | 105.39 | -9.76 | 156.87 | 0.4039 | -998.8 | 999999 | |
| 0.00 | 9.21 | 0.00 | 5.08 | -23.78 | 105.21 | -9.94 | 158.95 | 0.4418 | -404.0 | -776.5 | |
| 0.00 | 0.85 | 0.00 | 0.47 | -23.33 | 105.01 | -10.14 | 158.16 | 0.4363 | -891.0 | -699.6 | |
| 0.00 | 1.45 | 0.00 | 0.78 | -20.36 | 105.10 | -10.05 | 155.27 | 0.3929 | -790.0 | -646.0 | |
| 11.52 | -52.00 | 6.23 | -52.00 | -21.15 | 105.01 | -10.14 | 155.97 | 0.4049 | -1249.7 | 999999 | |
| 4.78 | 8.96 | 2.57 | 4.81 | -20.20 | 104.92 | -10.23 | 154.70 | 0.3919 | -976.0 | -698.3 | |
| 2.90 | -52.00 | 1.57 | -52.00 | -21.44 | 104.77 | -10.38 | 155.77 | 0.4106 | -658.8 | 999999 | |
| 0.00 | 1.11 | 0.00 | 0.60 | -21.47 | 104.47 | -10.68 | 155.21 | 0.4131 | -852.0 | -670.8 | |
| 0.00 | 1.96 | 0.00 | 1.06 | -20.27 | 104.53 | -10.62 | 153.95 | 0.3955 | -918.0 | -805.9 | |
| 0.00 | 1.19 | 0.00 | 0.65 | -21.28 | 104.46 | -10.70 | 154.97 | 0.4105 | -857.0 | -700.0 | |
| 0.00 | 2.30 | 0.00 | 1.24 | -19.82 | 104.37 | -10.78 | 153.08 | 0.3904 | -962.0 | -883.9 | |
| 0.00 | 1.02 | 0.00 | 0.57 | -23.75 | 104.06 | -11.09 | 156.76 | 0.4481 | -812.0 | -669.3 | |
| 0.00 | 0.51 | 0.00 | 0.27 | -19.13 | 104.41 | -10.74 | 152.30 | 0.3803 | -414.0 | -584.5 | |
| 0.00 | 2.81 | 0.00 | 1.53 | -21.38 | 104.16 | -10.99 | 154.47 | 0.4138 | -982.0 | -801.8 | |
| 0.00 | 1.54 | 0.00 | 0.83 | -20.01 | 104.19 | -10.96 | 152.94 | 0.3943 | -920.0 | -822.1 | |
| 3.33 | 21.75 | 1.83 | 11.94 | -22.53 | 103.68 | -11.48 | 154.79 | 0.4333 | -971.5 | -713.4 | |
| 1.45 | 3.50 | 0.79 | 1.91 | -21.51 | 103.73 | -11.42 | 153.76 | 0.4186 | -995.0 | -749.4 | |
| 0.00 | 2.99 | 0.00 | 1.63 | -21.98 | 103.59 | -11.56 | 154.04 | 0.4263 | -1087.0 | -967.8 | |
| 2.30 | -77.00 | 1.26 | -77.00 | -22.24 | 103.47 | -11.68 | 154.09 | 0.4307 | -901.3 | 999999 | |
| 2.73 | 7.25 | 1.51 | 4.00 | -23.11 | 103.36 | -11.79 | 154.82 | 0.4435 | -1074.1 | -679.3 | |
| 0.00 | 1.88 | 0.00 | 1.02 | -21.57 | 103.43 | -11.72 | 153.26 | 0.4217 | -997.0 | -781.6 | |
| 0.00 | 1.28 | 0.00 | 0.70 | -21.35 | 103.29 | -11.86 | 152.72 | 0.4196 | -669.0 | -602.9 | |
| 1.45 | 252.75 | 0.79 | 137.47 | -20.93 | 103.22 | -11.93 | 152.10 | 0.4144 | -1052.9 | -494.0 | |
| 1.45 | -84.00 | 0.79 | -84.00 | -20.68 | 103.21 | -11.94 | 151.77 | 0.4109 | -1136.1 | 999999 | |
| 0.00 | 1.11 | 0.00 | 0.61 | -22.11 | 103.09 | -12.06 | 153.23 | 0.4316 | -625.0 | -515.0 | |
| 5.46 | 5.97 | 3.02 | 3.31 | -23.30 | 102.95 | -12.20 | 154.27 | 0.4490 | -854.2 | -762.7 | |
| 0.77 | 1.96 | 0.42 | 1.07 | -21.63 | 103.07 | -12.08 | 152.64 | 0.4252 | -756.2 | -628.2 | |
| 0.00 | 2.90 | 0.00 | 1.59 | -22.05 | 102.77 | -12.38 | 152.56 | 0.4330 | -831.0 | -734.4 | |
| 13.99 | -84.00 | 7.58 | -84.00 | -20.14 | 102.77 | -12.38 | 150.22 | 0.4070 | -1328.8 | 999999 | |
| 29.00 | -84.00 | 15.79 | -84.00 | -20.81 | 102.68 | -12.47 | 150.90 | 0.4167 | -1225.4 | 999999 | |
| 1.71 | -84.00 | 0.93 | -84.00 | -21.35 | 102.54 | -12.61 | 151.29 | 0.4252 | -886.2 | 999999 | |
| 2.30 | -84.00 | 1.26 | -84.00 | -21.54 | 102.43 | -12.73 | 151.31 | 0.4287 | -798.0 | 999999 | |
| 1.54 | -84.00 | 0.84 | -84.00 | -21.73 | 102.41 | -12.74 | 151.51 | 0.4314 | -723.6 | 999999 | |
| 7.59 | 21.84 | 4.18 | 12.03 | -22.11 | 102.34 | -12.81 | 151.84 | 0.4371 | -756.8 | -446.7 | |
| 0.94 | -84.00 | 0.51 | -84.00 | -20.27 | 102.44 | -12.71 | 149.74 | 0.4114 | -822.3 | 999999 | |
| 0.00 | 1.71 | 0.00 | 0.94 | -22.15 | 101.81 | -13.34 | 150.92 | 0.4415 | -666.0 | -494.7 | |
| 0.00 | 2.13 | 0.00 | 1.19 | -23.37 | 100.86 | -14.29 | 150.71 | 0.4650 | -662.0 | -545.8 | |
| 0.00 | 1.54 | 0.00 | 0.84 | -20.84 | 101.02 | -14.13 | 147.86 | 0.4306 | -722.0 | -599.2 | |
| 0.00 | 2.99 | 0.00 | 1.64 | -20.34 | 100.36 | -14.79 | 145.99 | 0.4299 | -836.0 | -721.8 | |
| 0.00 | 1.36 | 0.00 | 0.74 | -18.27 | 100.48 | -14.67 | 143.15 | 0.4027 | -824.0 | -645.9 | |
| 0.00 | 1.36 | 0.00 | 0.75 | -20.09 | 99.08 | -16.08 | 143.44 | 0.4385 | -884.0 | -653.4 | |
| 0.00 | 1.19 | 0.00 | 0.67 | -20.41 | 97.29 | -17.86 | 141.08 | 0.4594 | -796.0 | -559.6 | |
| 0.00 | 1.19 | 0.00 | 0.66 | -18.40 | 97.46 | -17.69 | 138.23 | 0.4348 | -834.0 | -603.6 | |
| 0.00 | 1.28 | 0.00 | 0.71 | -20.28 | 97.11 | -18.04 | 140.62 | 0.4597 | -851.0 | -702.0 | |
| 0.00 | 2.64 | 0.00 | 1.48 | -20.54 | 96.75 | -18.40 | 140.45 | 0.4662 | -627.0 | -570.5 | |
| 0.00 | 0.94 | 0.00 | 0.52 | -18.31 | 96.81 | -18.34 | 137.09 | 0.4406 | -703.0 | -553.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
