SDO HMI 2011-12-04 22:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 33.95 | 56.14 | 22.14 | 36.60 | -18.20 | 77.41 | -36.64 | 119.32 | 0.6524 | -14.1 | -107.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-12-04 22:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.68 | 0.00 | 0.43 | -17.61 | 80.26 | -33.78 | 120.21 | 0.6156 | 715.0 | 655.5 | |
| 0.00 | 1.71 | 0.00 | 1.07 | -17.24 | 79.71 | -34.34 | 119.31 | 0.6202 | 797.0 | 580.2 | |
| 15.44 | 20.05 | 9.88 | 12.83 | -17.43 | 78.49 | -35.56 | 118.84 | 0.6357 | 853.0 | 510.1 | |
| 0.00 | 0.94 | 0.00 | 0.61 | -18.80 | 77.66 | -36.39 | 120.31 | 0.6528 | -762.0 | -647.5 | |
| 0.00 | 2.05 | 0.00 | 1.32 | -17.43 | 77.99 | -36.05 | 118.55 | 0.6416 | 380.0 | 331.3 | |
| 0.00 | 0.85 | 0.00 | 0.56 | -17.00 | 77.05 | -37.00 | 117.41 | 0.6506 | 635.0 | 553.5 | |
| 18.51 | 29.86 | 12.26 | 19.78 | -18.84 | 76.48 | -37.57 | 119.68 | 0.6665 | -862.5 | -572.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
