SDO HMI 2011-12-04 23:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 40.79 | 157.25 | 36.71 | 135.52 | 17.77 | 60.59 | -52.91 | 68.40 | 0.8185 | -455.0 | -201.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-12-04 23:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 20.90 | 126.62 | 17.44 | 105.90 | 17.03 | 61.74 | -51.76 | 68.99 | 0.8067 | -955.2 | -237.7 | |
| 0.00 | 1.11 | 0.00 | 0.97 | 17.33 | 59.92 | -53.57 | 69.08 | 0.8245 | -222.0 | -185.5 | |
| 13.40 | 19.03 | 12.78 | 18.16 | 21.01 | 57.09 | -56.40 | 65.49 | 0.8567 | -546.6 | -37.6 | |
| 0.43 | -3.00 | 0.41 | -3.00 | 21.17 | 56.83 | -56.67 | 65.37 | 0.8592 | 95.2 | 999999 | |
| 0.00 | 1.19 | 0.00 | 1.15 | 20.38 | 56.65 | -56.85 | 66.32 | 0.8591 | 587.0 | 475.9 | |
| 0.00 | 1.11 | 0.00 | 1.08 | 19.84 | 56.14 | -57.36 | 67.04 | 0.8623 | 373.0 | 399.2 | |
| 6.06 | 6.48 | 6.08 | 6.51 | 19.49 | 54.85 | -58.65 | 67.72 | 0.8720 | 595.0 | 484.2 | |
| 0.00 | 1.71 | 0.00 | 1.75 | 19.70 | 54.23 | -59.27 | 67.60 | 0.8772 | 175.0 | 184.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
