SDO HMI 2011-12-05 01:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 7.42 | 0.00 | 3.90 | -10.53 | 128.31 | 15.91 | 234.83 | 0.3313 | 845.8 | 681.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-12-05 01:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 2.47 | 0.00 | 1.30 | -9.91 | 129.08 | 16.68 | 237.66 | 0.3362 | 942.0 | 719.1 | |
| 0.00 | 1.02 | 0.00 | 0.54 | -10.18 | 128.87 | 16.47 | 236.65 | 0.3356 | 973.0 | 830.5 | |
| 0.00 | 1.71 | 0.00 | 0.90 | -11.53 | 128.23 | 15.83 | 232.26 | 0.3395 | 725.0 | 579.3 | |
| 0.00 | 1.28 | 0.00 | 0.67 | -11.50 | 128.04 | 15.64 | 232.01 | 0.3367 | 869.0 | 726.5 | |
| 0.00 | 0.94 | 0.00 | 0.49 | -9.42 | 126.13 | 13.74 | 233.91 | 0.2912 | 720.0 | 539.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
