SDO HMI 2011-12-05 06:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 5.63 | 13.99 | 6.40 | 16.25 | -16.98 | 46.26 | -63.40 | 109.03 | 0.9064 | 194.1 | -9.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-12-05 06:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 5.63 | 8.45 | 6.40 | 9.59 | -17.22 | 46.97 | -62.69 | 109.40 | 0.9017 | 456.9 | 333.3 | |
| 0.00 | 0.85 | 0.00 | 1.02 | -18.72 | 45.64 | -64.03 | 110.82 | 0.9127 | -276.0 | -201.6 | |
| 0.00 | 1.88 | 0.00 | 2.27 | -17.29 | 45.17 | -64.50 | 109.19 | 0.9142 | 142.0 | 35.6 | |
| 0.00 | 1.19 | 0.00 | 1.42 | -15.59 | 45.36 | -64.30 | 107.37 | 0.9112 | -516.0 | -432.3 | |
| 0.00 | 1.62 | 0.00 | 1.95 | -15.56 | 45.02 | -64.65 | 107.29 | 0.9135 | -255.0 | -216.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
