SDO HMI 2011-12-05 16:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 23.88 | 77.77 | 31.68 | 105.26 | 18.78 | 171.44 | 67.25 | 290.18 | 0.9293 | -47.1 | 81.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-12-05 16:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 4.35 | 23.96 | 7.21 | 40.18 | 18.88 | 175.93 | 71.74 | 289.71 | 0.9558 | -406.1 | 45.3 | |
| 4.52 | 8.10 | 6.72 | 12.04 | 19.02 | 173.67 | 69.49 | 290.09 | 0.9443 | -375.3 | -192.3 | |
| 1.36 | 2.05 | 1.82 | 2.72 | 18.37 | 171.24 | 67.06 | 289.70 | 0.9299 | -308.2 | -235.4 | |
| 0.00 | 2.39 | 0.00 | 3.04 | 17.48 | 170.17 | 65.99 | 288.88 | 0.9225 | -575.0 | -445.2 | |
| 3.50 | 4.26 | 4.47 | 5.45 | 18.00 | 170.32 | 66.14 | 289.42 | 0.9239 | -470.1 | -411.4 | |
| 0.00 | 3.33 | 0.00 | 3.84 | 18.17 | 167.50 | 63.31 | 290.01 | 0.9053 | 446.0 | 254.6 | |
| 0.77 | 30.95 | 0.88 | 34.93 | 18.80 | 167.08 | 62.90 | 290.77 | 0.9031 | -189.0 | 215.2 | |
| 3.16 | -7.00 | 3.59 | -7.00 | 18.70 | 166.95 | 62.76 | 290.69 | 0.9021 | 462.5 | 999999 | |
| 6.22 | -7.00 | 6.99 | -7.00 | 18.95 | 166.50 | 62.32 | 291.04 | 0.8992 | 642.7 | 999999 | |
| 0.00 | 2.73 | 0.00 | 3.06 | 19.36 | 166.37 | 62.18 | 291.51 | 0.8987 | 622.0 | 482.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
