SDO HMI 2011-12-06 04:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 7.25 | 17.49 | 6.04 | 14.34 | -16.01 | 46.63 | -50.95 | 110.50 | 0.7990 | -74.1 | 340.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-12-06 04:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 1.54 | 2.56 | 1.23 | 2.05 | -16.73 | 47.99 | -49.58 | 111.75 | 0.7873 | 701.8 | 624.3 | |
| 0.00 | 4.52 | 0.00 | 3.62 | -16.46 | 47.85 | -49.73 | 111.36 | 0.7880 | 525.0 | 584.3 | |
| 1.02 | 2.82 | 0.83 | 2.28 | -16.98 | 47.42 | -50.16 | 111.89 | 0.7936 | 495.2 | 406.4 | |
| 0.00 | 1.02 | 0.00 | 0.83 | -16.71 | 47.38 | -50.20 | 111.53 | 0.7933 | 433.0 | 332.9 | |
| 0.00 | 0.51 | 0.00 | 0.43 | -15.30 | 44.91 | -52.67 | 109.17 | 0.8142 | -417.0 | -366.0 | |
| 4.69 | 6.06 | 3.98 | 5.13 | -14.93 | 44.89 | -52.69 | 108.72 | 0.8136 | -624.4 | -432.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
