SDO HMI 2011-12-07 01:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 31.98 | 54.24 | 17.82 | 30.21 | -25.32 | 76.11 | -9.93 | 160.18 | 0.4600 | -160.1 | -48.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-12-07 01:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 10.75 | 13.39 | 5.94 | 7.40 | -25.08 | 78.44 | -7.60 | 164.31 | 0.4449 | 982.7 | 720.2 | |
| 2.64 | 8.53 | 1.46 | 4.70 | -24.56 | 77.36 | -8.68 | 161.83 | 0.4421 | 961.4 | 839.2 | |
| 0.00 | 1.19 | 0.00 | 0.66 | -24.99 | 76.10 | -9.94 | 159.80 | 0.4548 | 680.0 | 447.3 | |
| 1.62 | 29.25 | 0.91 | 16.38 | -25.31 | 75.08 | -10.96 | 158.22 | 0.4652 | -1111.5 | -680.8 | |
| 0.00 | 1.88 | 0.00 | 1.07 | -27.86 | 74.76 | -11.28 | 159.80 | 0.5027 | -709.0 | -570.8 | |
| 16.97 | -4.00 | 9.51 | -4.00 | -25.51 | 74.76 | -11.28 | 157.84 | 0.4698 | -985.6 | 999999 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
