SDO HMI 2011-12-07 04:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 34.04 | 43.92 | 18.85 | 24.32 | -25.20 | 76.30 | -8.10 | 163.51 | 0.4491 | -35.2 | 48.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-12-07 04:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 10.41 | 12.28 | 5.73 | 6.76 | -25.14 | 78.47 | -5.93 | 167.65 | 0.4390 | 962.7 | 552.3 | |
| 5.97 | 8.87 | 3.28 | 4.87 | -24.52 | 77.42 | -6.98 | 165.16 | 0.4334 | 990.4 | 755.6 | |
| 0.00 | 1.02 | 0.00 | 0.57 | -24.81 | 76.09 | -8.31 | 162.73 | 0.4436 | 704.0 | 545.2 | |
| 17.66 | 21.75 | 9.84 | 12.12 | -25.53 | 74.65 | -9.75 | 160.57 | 0.4613 | -1033.4 | -797.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
