SDO HMI 2011-12-07 07:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 2.22 | 11.34 | 1.17 | 6.04 | -20.28 | 76.68 | -6.08 | 164.55 | 0.3642 | -395.2 | -255.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-12-07 07:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 2.22 | 0.00 | 1.16 | -17.75 | 80.30 | -2.47 | 172.39 | 0.3109 | 538.0 | 436.1 | |
| 0.00 | 0.77 | 0.00 | 0.40 | -18.21 | 80.07 | -2.69 | 171.93 | 0.3191 | 771.0 | 578.6 | |
| 2.22 | 3.41 | 1.17 | 1.79 | -18.49 | 76.91 | -5.85 | 163.16 | 0.3350 | -939.1 | -847.2 | |
| 0.00 | 0.94 | 0.00 | 0.49 | -17.97 | 75.56 | -7.21 | 158.98 | 0.3341 | -905.0 | -728.9 | |
| 0.00 | 1.19 | 0.00 | 0.63 | -18.25 | 75.42 | -7.34 | 158.93 | 0.3392 | -650.0 | -529.4 | |
| 0.00 | 0.77 | 0.00 | 0.43 | -26.44 | 74.47 | -8.29 | 163.89 | 0.4674 | -601.0 | -459.1 | |
| 0.00 | 1.02 | 0.00 | 0.57 | -26.21 | 73.92 | -8.84 | 162.73 | 0.4664 | -570.0 | -463.1 | |
| 0.00 | 1.02 | 0.00 | 0.57 | -26.14 | 73.03 | -9.74 | 161.06 | 0.4698 | -713.0 | -519.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
