SDO HMI 2011-12-07 15:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 16.63 | 37.07 | 9.15 | 20.17 | -23.87 | 75.31 | -3.08 | 173.63 | 0.4112 | -769.2 | -509.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-12-07 15:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.94 | 0.00 | 0.49 | -17.89 | 82.50 | 4.11 | 192.47 | 0.3176 | 394.0 | 375.6 | |
| 0.00 | 2.98 | 0.00 | 1.56 | -18.29 | 80.05 | 1.66 | 185.00 | 0.3181 | 1029.0 | 809.7 | |
| 0.77 | 2.64 | 0.40 | 1.38 | -18.51 | 77.00 | -1.38 | 175.89 | 0.3213 | -1123.7 | -935.3 | |
| 0.00 | 2.56 | 0.00 | 1.33 | -17.86 | 75.92 | -2.46 | 172.44 | 0.3124 | -944.0 | -704.7 | |
| 0.00 | 1.02 | 0.00 | 0.53 | -18.04 | 75.88 | -2.50 | 172.42 | 0.3155 | -890.0 | -757.0 | |
| 0.00 | 1.70 | 0.00 | 0.96 | -27.81 | 74.76 | -3.62 | 173.19 | 0.4734 | -927.0 | -729.6 | |
| 2.05 | 4.09 | 1.13 | 2.25 | -25.40 | 74.41 | -3.97 | 171.73 | 0.4368 | -988.4 | -896.0 | |
| 13.81 | 19.01 | 7.62 | 10.49 | -25.82 | 74.36 | -4.02 | 171.79 | 0.4435 | -978.0 | -772.2 | |
| 0.00 | 2.13 | 0.00 | 1.18 | -25.86 | 73.67 | -4.71 | 170.41 | 0.4457 | -942.0 | -747.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
