SDO HMI 2011-12-07 19:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 10.06 | 25.31 | 6.07 | 15.19 | 8.08 | 42.58 | -33.59 | 75.71 | 0.5673 | 176.0 | -87.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-12-07 19:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.70 | 0.00 | 1.01 | 8.92 | 44.04 | -32.13 | 73.68 | 0.5497 | -670.0 | -489.6 | |
| 0.00 | 0.68 | 0.00 | 0.40 | 8.65 | 43.99 | -32.18 | 74.18 | 0.5494 | -597.0 | -534.1 | |
| 0.00 | 1.45 | 0.00 | 0.86 | 9.22 | 43.90 | -32.27 | 73.21 | 0.5527 | -721.0 | -662.9 | |
| 0.00 | 0.77 | 0.00 | 0.45 | 8.23 | 43.82 | -32.35 | 74.99 | 0.5505 | -659.0 | -542.6 | |
| 2.22 | 6.39 | 1.31 | 3.79 | 7.88 | 43.71 | -32.46 | 75.67 | 0.5509 | -827.9 | -684.6 | |
| 5.45 | 8.27 | 3.29 | 4.98 | 7.70 | 42.16 | -34.01 | 76.53 | 0.5722 | 912.7 | 672.2 | |
| 0.00 | 0.77 | 0.00 | 0.46 | 7.85 | 41.78 | -34.39 | 76.40 | 0.5779 | 525.0 | 394.7 | |
| 0.00 | 0.85 | 0.00 | 0.52 | 7.87 | 41.60 | -34.57 | 76.41 | 0.5805 | 628.0 | 551.0 | |
| 0.00 | 1.19 | 0.00 | 0.73 | 8.02 | 41.00 | -35.17 | 76.36 | 0.5892 | 828.0 | 647.0 | |
| 2.39 | 3.24 | 1.47 | 1.99 | 8.47 | 40.66 | -35.51 | 75.73 | 0.5951 | 713.4 | 649.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
