SDO HMI 2011-12-07 23:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 7.93 | 31.36 | 4.33 | 17.10 | -24.37 | 74.55 | 0.59 | 181.68 | 0.4154 | -862.1 | -663.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-12-07 23:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.45 | 0.00 | 0.76 | -18.53 | 77.19 | 3.22 | 189.50 | 0.3245 | -734.0 | -587.2 | |
| 0.00 | 2.81 | 0.00 | 1.47 | -18.56 | 77.00 | 3.04 | 188.94 | 0.3245 | -932.0 | -768.3 | |
| 1.11 | 2.05 | 0.58 | 1.07 | -18.03 | 75.78 | 1.82 | 185.55 | 0.3133 | -977.5 | -916.8 | |
| 0.00 | 0.85 | 0.00 | 0.48 | -28.10 | 74.58 | 0.62 | 181.16 | 0.4739 | -666.0 | -517.2 | |
| 0.00 | 0.94 | 0.00 | 0.52 | -25.81 | 74.57 | 0.61 | 181.25 | 0.4382 | -660.0 | -602.6 | |
| 4.18 | 12.87 | 2.30 | 7.09 | -25.77 | 74.24 | 0.28 | 180.58 | 0.4376 | -1110.7 | -675.3 | |
| 2.64 | 3.58 | 1.45 | 1.96 | -25.45 | 74.11 | 0.15 | 180.31 | 0.4324 | -912.8 | -689.6 | |
| 0.00 | 1.70 | 0.00 | 0.94 | -25.71 | 73.95 | -0.02 | 179.97 | 0.4365 | -889.0 | -691.2 | |
| 0.00 | 1.36 | 0.00 | 0.75 | -26.40 | 73.48 | -0.48 | 179.04 | 0.4474 | -706.0 | -462.3 | |
| 0.00 | 2.39 | 0.00 | 1.32 | -25.97 | 73.45 | -0.51 | 178.96 | 0.4407 | -849.0 | -694.5 | |
| 0.00 | 1.36 | 0.00 | 0.74 | -24.73 | 73.13 | -0.83 | 178.20 | 0.4212 | -749.0 | -526.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
