SDO HMI 2011-12-08 01:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 55.75 | 195.93 | 33.67 | 118.39 | 18.38 | 103.10 | 30.24 | 303.38 | 0.5745 | -319.1 | -196.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-12-08 01:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 1.88 | 25.58 | 1.14 | 15.52 | 16.98 | 104.52 | 31.65 | 300.15 | 0.5826 | 565.6 | 448.5 | |
| 12.02 | -1.00 | 7.29 | -1.00 | 17.04 | 104.20 | 31.34 | 300.47 | 0.5791 | 892.5 | 999999 | |
| 0.85 | 4.69 | 0.51 | 2.81 | 16.83 | 103.22 | 30.36 | 300.84 | 0.5657 | 808.7 | 614.2 | |
| 25.92 | 127.46 | 15.75 | 77.52 | 18.78 | 103.49 | 30.63 | 303.68 | 0.5818 | -1157.1 | -336.0 | |
| 1.02 | -4.00 | 0.62 | -4.00 | 19.22 | 103.29 | 30.42 | 304.50 | 0.5825 | -571.5 | 999999 | |
| 0.00 | 0.94 | 0.00 | 0.56 | 17.75 | 102.32 | 29.46 | 303.02 | 0.5608 | -727.0 | -572.0 | |
| 0.00 | 1.28 | 0.00 | 0.76 | 18.10 | 102.20 | 29.34 | 303.65 | 0.5617 | -573.0 | -481.2 | |
| 5.88 | 10.23 | 3.50 | 6.08 | 17.72 | 101.96 | 29.10 | 303.27 | 0.5561 | -941.3 | -321.3 | |
| 2.90 | 3.24 | 1.73 | 1.93 | 19.09 | 101.50 | 28.64 | 305.79 | 0.5605 | -863.6 | -779.2 | |
| 3.75 | 14.07 | 2.22 | 8.33 | 18.34 | 101.22 | 28.36 | 304.87 | 0.5517 | -857.6 | -296.8 | |
| 1.53 | -10.00 | 0.91 | -10.00 | 18.44 | 100.95 | 28.09 | 305.25 | 0.5492 | 482.0 | 999999 | |
| 0.00 | 0.68 | 0.00 | 0.40 | 18.13 | 100.61 | 27.75 | 305.06 | 0.5428 | 663.0 | 506.1 | |
| 0.00 | 2.13 | 0.00 | 1.23 | 16.18 | 99.37 | 26.50 | 302.97 | 0.5130 | 722.0 | 423.0 | |
| 0.00 | 1.19 | 0.00 | 0.69 | 16.70 | 99.34 | 26.48 | 303.89 | 0.5165 | 809.0 | 652.7 | |
| 0.00 | 0.60 | 0.00 | 0.34 | 16.39 | 99.16 | 26.29 | 303.53 | 0.5119 | 776.0 | 548.0 | |
| 0.00 | 0.94 | 0.00 | 0.53 | 15.01 | 98.49 | 25.63 | 301.74 | 0.4933 | 576.0 | 335.7 | |
| 0.00 | 1.02 | 0.00 | 0.60 | 19.97 | 99.22 | 26.36 | 309.25 | 0.5410 | 723.0 | 602.0 | |
| 0.00 | 1.88 | 0.00 | 1.09 | 19.50 | 97.99 | 25.13 | 309.78 | 0.5229 | 684.0 | 551.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
