SDO HMI 2011-12-08 05:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 10.65 | 0.00 | 5.60 | -18.01 | 77.70 | 7.02 | 200.54 | 0.3326 | -15.7 | 38.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-12-08 05:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 2.30 | 0.00 | 1.21 | -17.71 | 79.09 | 8.42 | 204.62 | 0.3362 | 1136.0 | 866.8 | |
| 0.00 | 1.79 | 0.00 | 0.94 | -18.05 | 78.95 | 8.28 | 203.83 | 0.3403 | 807.0 | 681.3 | |
| 0.00 | 1.53 | 0.00 | 0.81 | -17.89 | 78.72 | 8.05 | 203.44 | 0.3365 | 670.0 | 602.9 | |
| 0.00 | 0.94 | 0.00 | 0.49 | -18.64 | 77.00 | 6.32 | 198.08 | 0.3378 | -853.0 | -758.5 | |
| 0.00 | 2.30 | 0.00 | 1.21 | -18.11 | 76.39 | 5.71 | 196.92 | 0.3265 | -800.0 | -635.1 | |
| 0.00 | 1.79 | 0.00 | 0.94 | -17.99 | 75.82 | 5.15 | 195.44 | 0.3219 | -1054.0 | -876.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
