SDO HMI 2011-12-08 11:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 27.45 | 166.89 | 50.11 | 308.74 | -17.02 | 353.70 | -73.70 | 107.68 | 0.9644 | 244.2 | 65.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-12-08 11:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.77 | 0.00 | 1.30 | -19.62 | 355.54 | -71.86 | 110.55 | 0.9573 | -146.0 | -40.6 | |
| 3.84 | 159.90 | 7.17 | 297.17 | -17.81 | 353.58 | -73.82 | 108.48 | 0.9653 | 369.8 | 65.9 | |
| 14.06 | -2.00 | 25.85 | -2.00 | -16.91 | 353.77 | -73.63 | 107.57 | 0.9641 | 571.1 | 999999 | |
| 3.84 | 6.22 | 6.30 | 10.27 | -14.96 | 355.58 | -71.82 | 105.70 | 0.9548 | -248.8 | 82.4 | |
| 5.71 | -2.00 | 10.79 | -2.00 | -17.00 | 353.33 | -74.07 | 107.63 | 0.9661 | -298.6 | 999999 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
