SDO HMI 2011-12-08 20:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 1.62 | 7.93 | 0.91 | 4.47 | -26.27 | 74.03 | 11.59 | 202.18 | 0.4792 | -520.3 | -445.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-12-08 20:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.19 | 0.00 | 0.67 | -25.75 | 75.38 | 12.94 | 204.94 | 0.4803 | 629.0 | 535.2 | |
| 0.00 | 1.45 | 0.00 | 0.82 | -27.40 | 74.04 | 11.60 | 201.24 | 0.4949 | -893.0 | -689.9 | |
| 0.00 | 0.94 | 0.00 | 0.53 | -26.01 | 73.80 | 11.36 | 202.01 | 0.4742 | -630.0 | -496.3 | |
| 1.62 | 3.07 | 0.91 | 1.72 | -25.59 | 73.66 | 11.22 | 202.14 | 0.4674 | -891.9 | -729.6 | |
| 0.00 | 1.28 | 0.00 | 0.73 | -27.27 | 73.79 | 11.35 | 200.93 | 0.4917 | -849.0 | -720.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
