SDO HMI 2011-12-09 17:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 24.19 | 95.67 | 12.23 | 48.33 | 7.96 | 43.05 | -7.87 | 43.17 | 0.1975 | -7.0 | 3.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-12-09 17:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.87 | 0.00 | 0.94 | 7.90 | 45.96 | -4.96 | 31.42 | 0.1651 | -904.0 | -692.3 | |
| 0.00 | 4.86 | 0.00 | 2.44 | 7.75 | 45.66 | -5.26 | 33.42 | 0.1657 | -1259.0 | -1056.4 | |
| 0.00 | 2.13 | 0.00 | 1.07 | 7.51 | 45.37 | -5.56 | 35.70 | 0.1652 | -997.0 | -766.1 | |
| 4.68 | 5.03 | 2.35 | 2.52 | 7.24 | 45.01 | -5.91 | 38.40 | 0.1652 | -1071.5 | -929.2 | |
| 0.00 | 1.02 | 0.00 | 0.51 | 8.02 | 44.97 | -5.95 | 35.81 | 0.1763 | -794.0 | -639.8 | |
| 0.00 | 8.77 | 0.00 | 4.41 | 7.57 | 44.92 | -6.00 | 37.62 | 0.1707 | -1211.0 | -976.2 | |
| 0.00 | 1.11 | 0.00 | 0.56 | 7.84 | 44.88 | -6.04 | 36.82 | 0.1747 | -986.0 | -823.2 | |
| 0.00 | 0.77 | 0.00 | 0.39 | 7.36 | 44.71 | -6.21 | 39.33 | 0.1701 | -790.0 | -606.9 | |
| 0.00 | 3.32 | 0.00 | 1.67 | 7.12 | 44.65 | -6.27 | 40.50 | 0.1676 | -924.0 | -830.0 | |
| 0.00 | 0.94 | 0.00 | 0.47 | 7.54 | 44.56 | -6.36 | 39.34 | 0.1741 | -881.0 | -710.0 | |
| 2.21 | 10.65 | 1.12 | 5.36 | 8.02 | 44.34 | -6.58 | 38.57 | 0.1828 | -923.7 | -696.8 | |
| 0.00 | 2.90 | 0.00 | 1.46 | 7.15 | 44.03 | -6.90 | 43.09 | 0.1752 | -952.0 | -715.0 | |
| 0.00 | 3.07 | 0.00 | 1.55 | 7.45 | 42.85 | -8.07 | 46.42 | 0.1931 | 1012.0 | 887.5 | |
| 7.84 | 14.48 | 3.97 | 7.33 | 8.41 | 42.41 | -8.51 | 44.51 | 0.2099 | 1103.9 | 782.0 | |
| 0.00 | 2.38 | 0.00 | 1.21 | 8.73 | 42.25 | -8.67 | 43.94 | 0.2158 | 761.0 | 643.8 | |
| 2.30 | -14.00 | 1.16 | -14.00 | 8.11 | 42.23 | -8.69 | 46.11 | 0.2084 | 1076.5 | 999999 | |
| 0.00 | 0.77 | 0.00 | 0.39 | 7.99 | 42.00 | -8.93 | 47.30 | 0.2100 | 845.0 | 571.6 | |
| 2.73 | 26.06 | 1.38 | 13.23 | 8.14 | 41.27 | -9.65 | 48.99 | 0.2210 | 1162.1 | 943.9 | |
| 2.56 | -18.00 | 1.30 | -18.00 | 8.29 | 41.02 | -9.90 | 49.18 | 0.2258 | 984.5 | 999999 | |
| 1.87 | -18.00 | 0.95 | -18.00 | 8.05 | 41.00 | -9.92 | 50.07 | 0.2235 | 1045.2 | 999999 | |
| 0.00 | 5.54 | 0.00 | 2.82 | 8.47 | 40.71 | -10.21 | 49.44 | 0.2318 | 941.0 | 794.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
