SDO HMI 2011-12-10 09:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 45.93 | 337.62 | 59.26 | 431.16 | -23.00 | 107.49 | 65.35 | 245.06 | 0.9242 | 573.4 | 258.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-12-10 09:58:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 2.30 | 314.26 | 3.14 | 403.91 | -23.27 | 109.00 | 66.86 | 245.03 | 0.9334 | -246.0 | 269.8 | |
| 0.00 | 1.11 | 0.00 | 1.37 | -21.14 | 106.74 | 64.60 | 246.94 | 0.9174 | 479.0 | 455.3 | |
| 0.00 | 1.62 | 0.00 | 2.03 | -21.81 | 107.07 | 64.93 | 246.28 | 0.9203 | 528.0 | 485.0 | |
| 0.00 | 3.41 | 0.00 | 4.12 | -21.08 | 106.24 | 64.10 | 246.92 | 0.9142 | 516.0 | 284.1 | |
| 40.65 | -1.00 | 52.57 | -1.00 | -23.02 | 107.63 | 65.49 | 245.07 | 0.9251 | 718.7 | 999999 | |
| 1.11 | -1.00 | 1.36 | -1.00 | -23.22 | 106.29 | 64.14 | 244.62 | 0.9171 | 641.5 | 999999 | |
| 0.00 | 0.94 | 0.00 | 1.07 | -21.75 | 104.50 | 62.35 | 245.87 | 0.9034 | 255.0 | 198.8 | |
| 0.00 | 1.02 | 0.00 | 1.15 | -21.31 | 104.02 | 61.88 | 246.27 | 0.8995 | -137.0 | -99.5 | |
| 0.00 | 2.05 | 0.00 | 2.19 | -20.23 | 102.68 | 60.54 | 247.19 | 0.8882 | -584.0 | -539.8 | |
| 1.87 | 12.27 | 2.19 | 14.42 | -23.70 | 104.68 | 62.54 | 243.79 | 0.9074 | -252.1 | 103.1 | |
| 0.00 | 0.94 | 0.00 | 0.90 | -20.94 | 98.67 | 56.53 | 245.51 | 0.8582 | -389.0 | -322.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
