SDO HMI 2011-12-10 20:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 4.43 | 24.27 | 3.14 | 17.26 | -19.09 | 78.69 | 42.61 | 243.17 | 0.7192 | -5.9 | -92.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-12-10 20:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.45 | 0.00 | 1.08 | -17.82 | 81.83 | 45.75 | 246.08 | 0.7483 | 739.0 | 516.6 | |
| 0.00 | 1.19 | 0.00 | 0.88 | -18.26 | 81.18 | 45.09 | 245.28 | 0.7428 | 644.0 | 471.0 | |
| 0.00 | 0.77 | 0.00 | 0.55 | -17.80 | 79.72 | 43.64 | 245.32 | 0.7255 | 671.0 | 631.7 | |
| 4.43 | 14.90 | 3.14 | 10.57 | -19.23 | 78.51 | 42.42 | 242.92 | 0.7177 | -752.1 | -341.8 | |
| 0.00 | 0.68 | 0.00 | 0.49 | -20.01 | 78.76 | 42.68 | 242.01 | 0.7237 | 558.0 | 468.0 | |
| 0.00 | 0.60 | 0.00 | 0.42 | -18.92 | 78.07 | 41.99 | 243.14 | 0.7117 | 470.0 | 406.6 | |
| 0.00 | 1.70 | 0.00 | 1.19 | -18.58 | 77.92 | 41.84 | 243.53 | 0.7087 | 287.0 | 337.6 | |
| 0.00 | 2.38 | 0.00 | 1.66 | -19.80 | 77.25 | 41.17 | 241.60 | 0.7065 | -543.0 | -416.5 | |
| 0.00 | 0.60 | 0.00 | 0.42 | -19.99 | 77.15 | 41.06 | 241.30 | 0.7062 | -530.0 | -464.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
