SDO HMI 2011-12-11 09:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 24.78 | 184.02 | 64.97 | 472.99 | -23.00 | 107.32 | 78.36 | 246.64 | 0.9829 | 338.0 | 257.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-12-11 09:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 2.30 | 0.00 | 6.02 | -20.81 | 107.51 | 78.54 | 248.88 | 0.9830 | 380.0 | 316.4 | |
| 0.00 | 1.02 | 0.00 | 2.71 | -21.00 | 107.55 | 78.58 | 248.69 | 0.9832 | 455.0 | 469.6 | |
| 0.00 | 2.30 | 0.00 | 5.60 | -21.07 | 106.58 | 77.61 | 248.55 | 0.9802 | 451.0 | 364.0 | |
| 1.87 | 2.73 | 4.49 | 6.50 | -21.32 | 106.28 | 77.32 | 248.27 | 0.9793 | 480.5 | 365.3 | |
| 5.28 | 175.67 | 15.18 | 452.16 | -23.10 | 108.26 | 79.30 | 246.60 | 0.9856 | -312.9 | 253.0 | |
| 17.63 | -5.00 | 45.30 | -5.00 | -23.08 | 107.03 | 78.07 | 246.54 | 0.9821 | 536.0 | 999999 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
