SDO HMI 2011-12-11 19:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 87.01 | 479.42 | 52.71 | 290.27 | -17.48 | 352.28 | -31.18 | 120.78 | 0.5772 | 845.3 | 364.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-12-11 19:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.94 | 0.00 | 0.56 | -18.25 | 354.58 | -28.88 | 123.78 | 0.5541 | 697.0 | 440.0 | |
| 0.00 | 1.19 | 0.00 | 0.72 | -18.71 | 353.81 | -29.65 | 123.88 | 0.5666 | 555.0 | 441.4 | |
| 0.00 | 2.47 | 0.00 | 1.49 | -18.93 | 353.66 | -29.80 | 124.10 | 0.5699 | -203.0 | -175.3 | |
| 0.00 | 0.85 | 0.00 | 0.50 | -16.18 | 354.12 | -29.34 | 120.06 | 0.5459 | -657.0 | -494.5 | |
| 0.00 | 1.02 | 0.00 | 0.61 | -18.65 | 353.64 | -29.82 | 123.65 | 0.5682 | 644.0 | 488.8 | |
| 0.00 | 0.94 | 0.00 | 0.54 | -12.83 | 354.47 | -28.99 | 114.53 | 0.5216 | 667.0 | 505.6 | |
| 0.00 | 2.81 | 0.00 | 1.69 | -18.28 | 353.46 | -30.00 | 122.93 | 0.5678 | 333.0 | 367.4 | |
| 0.00 | 0.94 | 0.00 | 0.56 | -17.97 | 353.42 | -30.05 | 122.40 | 0.5663 | 422.0 | 364.0 | |
| 0.00 | 1.19 | 0.00 | 0.73 | -19.90 | 352.92 | -30.54 | 124.97 | 0.5854 | -792.0 | -586.4 | |
| 0.00 | 0.94 | 0.00 | 0.56 | -18.21 | 353.15 | -30.31 | 122.59 | 0.5712 | 878.0 | 698.5 | |
| 0.00 | 1.45 | 0.00 | 0.84 | -11.72 | 353.95 | -29.52 | 112.18 | 0.5231 | 603.0 | 470.8 | |
| 15.15 | 427.56 | 9.19 | 258.70 | -18.43 | 352.57 | -30.89 | 122.47 | 0.5796 | 1145.4 | 389.1 | |
| 53.13 | -12.00 | 32.09 | -12.00 | -17.22 | 352.37 | -31.09 | 120.44 | 0.5744 | 1290.8 | 999999 | |
| 5.62 | 10.64 | 3.44 | 6.52 | -18.55 | 351.78 | -31.69 | 122.08 | 0.5899 | 658.4 | 492.6 | |
| 0.00 | 0.94 | 0.00 | 0.56 | -15.93 | 352.17 | -31.29 | 118.24 | 0.5692 | 118.0 | 103.5 | |
| 0.00 | 1.53 | 0.00 | 0.94 | -18.96 | 351.51 | -31.95 | 122.49 | 0.5957 | -191.0 | -154.8 | |
| 1.62 | -12.00 | 0.98 | -12.00 | -17.16 | 351.76 | -31.70 | 119.92 | 0.5815 | 694.8 | 999999 | |
| 5.19 | -12.00 | 3.17 | -12.00 | -17.56 | 351.65 | -31.81 | 120.46 | 0.5853 | 796.9 | 999999 | |
| 0.00 | 0.85 | 0.00 | 0.52 | -18.39 | 351.44 | -32.02 | 121.60 | 0.5930 | 746.0 | 605.2 | |
| 0.00 | 1.11 | 0.00 | 0.68 | -18.61 | 351.21 | -32.25 | 121.77 | 0.5971 | 425.0 | 365.5 | |
| 2.30 | 4.00 | 1.39 | 2.42 | -15.07 | 351.09 | -32.37 | 116.15 | 0.5782 | -702.6 | -381.6 | |
| 4.00 | 5.53 | 2.45 | 3.39 | -16.35 | 350.75 | -32.71 | 117.98 | 0.5895 | 615.8 | 491.9 | |
| 0.00 | 6.56 | 0.00 | 4.08 | -18.70 | 350.23 | -33.23 | 121.22 | 0.6093 | 649.0 | 495.6 | |
| 0.00 | 3.49 | 0.00 | 2.14 | -15.10 | 350.21 | -33.25 | 115.67 | 0.5896 | -761.0 | -648.0 | |
| 0.00 | 1.19 | 0.00 | 0.73 | -16.14 | 350.02 | -33.44 | 117.19 | 0.5974 | -759.0 | -599.1 | |
| 0.00 | 1.28 | 0.00 | 0.79 | -17.18 | 349.77 | -33.69 | 118.64 | 0.6061 | -708.0 | -643.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
