SDO HMI 2011-12-11 20:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 96.80 | 482.74 | 58.31 | 290.73 | -17.53 | 352.19 | -30.72 | 121.20 | 0.5717 | 809.8 | 352.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-12-11 20:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.28 | 0.00 | 0.76 | -18.56 | 353.86 | -29.05 | 124.13 | 0.5583 | 447.0 | 388.7 | |
| 0.00 | 0.85 | 0.00 | 0.50 | -16.03 | 354.19 | -28.72 | 120.29 | 0.5370 | -680.0 | -576.7 | |
| 0.00 | 1.02 | 0.00 | 0.61 | -19.50 | 353.57 | -29.34 | 125.34 | 0.5684 | -534.0 | -517.2 | |
| 0.00 | 2.89 | 0.00 | 1.73 | -18.90 | 353.65 | -29.26 | 124.49 | 0.5632 | -200.0 | -193.6 | |
| 0.00 | 1.11 | 0.00 | 0.66 | -18.66 | 353.63 | -29.28 | 124.09 | 0.5617 | 686.0 | 483.0 | |
| 0.00 | 0.85 | 0.00 | 0.51 | -18.56 | 353.50 | -29.41 | 123.84 | 0.5626 | 744.0 | 563.2 | |
| 0.00 | 0.85 | 0.00 | 0.52 | -19.90 | 352.91 | -30.00 | 125.41 | 0.5791 | -716.0 | -564.9 | |
| 20.43 | 442.48 | 12.33 | 266.22 | -18.50 | 352.54 | -30.37 | 122.97 | 0.5737 | 1106.0 | 378.4 | |
| 56.87 | -8.00 | 34.15 | -8.00 | -17.23 | 352.39 | -30.52 | 120.86 | 0.5673 | 1315.2 | 999999 | |
| 5.11 | 10.64 | 3.11 | 6.49 | -18.59 | 351.73 | -31.18 | 122.49 | 0.5841 | 747.6 | 507.0 | |
| 0.94 | -10.00 | 0.57 | -10.00 | -18.80 | 351.46 | -31.45 | 122.63 | 0.5887 | 505.8 | 999999 | |
| 5.96 | -8.00 | 3.61 | -8.00 | -17.60 | 351.63 | -31.28 | 120.89 | 0.5789 | 789.3 | 999999 | |
| 0.34 | -8.00 | 0.21 | -8.00 | -17.07 | 351.62 | -31.28 | 120.06 | 0.5758 | 649.5 | 999999 | |
| 0.00 | 1.19 | 0.00 | 0.73 | -18.46 | 351.31 | -31.59 | 122.00 | 0.5882 | 659.0 | 503.0 | |
| 0.77 | -8.00 | 0.46 | -8.00 | -17.10 | 351.47 | -31.43 | 120.00 | 0.5778 | 464.3 | 999999 | |
| 0.00 | 0.94 | 0.00 | 0.57 | -18.65 | 351.17 | -31.74 | 122.18 | 0.5912 | 455.0 | 389.5 | |
| 2.21 | 2.81 | 1.33 | 1.69 | -15.07 | 351.11 | -31.80 | 116.52 | 0.5708 | -679.3 | -377.3 | |
| 4.17 | -8.00 | 2.54 | -8.00 | -16.39 | 350.70 | -32.21 | 118.36 | 0.5833 | 592.6 | 999999 | |
| 0.00 | 8.17 | 0.00 | 5.06 | -18.68 | 350.20 | -32.71 | 121.54 | 0.6029 | 625.0 | 508.2 | |
| 0.00 | 1.19 | 0.00 | 0.72 | -15.47 | 350.65 | -32.26 | 116.86 | 0.5789 | -629.0 | -457.9 | |
| 0.00 | 2.04 | 0.00 | 1.24 | -15.22 | 350.22 | -32.69 | 116.20 | 0.5831 | -796.0 | -647.8 | |
| 0.00 | 1.02 | 0.00 | 0.63 | -17.62 | 349.76 | -33.15 | 119.65 | 0.6020 | -842.0 | -705.7 | |
| 0.00 | 0.85 | 0.00 | 0.52 | -16.08 | 350.06 | -32.85 | 117.46 | 0.5896 | -702.0 | -569.6 | |
| 0.00 | 0.77 | 0.00 | 0.47 | -16.26 | 349.99 | -32.92 | 117.71 | 0.5915 | -690.0 | -471.1 | |
| 0.00 | 0.51 | 0.00 | 0.32 | -17.03 | 349.69 | -33.22 | 118.71 | 0.5994 | -598.0 | -462.7 | |
| 0.00 | 1.28 | 0.00 | 0.78 | -15.90 | 349.58 | -33.33 | 116.87 | 0.5946 | -702.0 | -548.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
