SDO HMI 2011-12-13 03:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 12.18 | 37.81 | 22.51 | 73.24 | -18.68 | 80.35 | 74.46 | 250.81 | 0.9673 | 325.7 | 228.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-12-13 03:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 4.34 | 0.00 | 10.04 | -18.60 | 83.09 | 77.21 | 251.09 | 0.9780 | 330.0 | 120.5 | |
| 0.00 | 0.77 | 0.00 | 1.56 | -17.34 | 81.38 | 75.49 | 252.27 | 0.9713 | 146.0 | 139.0 | |
| 0.00 | 0.68 | 0.00 | 1.33 | -16.79 | 80.73 | 74.84 | 252.80 | 0.9685 | 304.0 | 244.0 | |
| 0.00 | 1.45 | 0.00 | 2.99 | -18.99 | 81.36 | 75.47 | 250.57 | 0.9717 | 276.0 | 290.1 | |
| 3.58 | 25.55 | 6.69 | 47.42 | -18.35 | 79.94 | 74.06 | 251.13 | 0.9657 | 508.1 | 318.1 | |
| 0.00 | 2.04 | 0.00 | 4.05 | -19.00 | 80.74 | 74.86 | 250.52 | 0.9693 | -118.0 | -30.0 | |
| 0.68 | 2.98 | 1.33 | 5.85 | -19.40 | 80.55 | 74.66 | 250.09 | 0.9686 | 210.9 | 165.1 | |
| 5.71 | -5.00 | 10.50 | -5.00 | -18.76 | 79.51 | 73.63 | 250.67 | 0.9640 | 499.3 | 999999 | |
| 2.21 | -5.00 | 3.99 | -5.00 | -18.92 | 79.25 | 73.37 | 250.49 | 0.9629 | -225.8 | 999999 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
