SDO HMI 2011-12-13 20:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 18.13 | 84.12 | 17.68 | 81.82 | 20.89 | 299.87 | -56.69 | 65.08 | 0.8617 | -149.4 | -99.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-12-13 20:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 3.66 | 5.45 | 3.21 | 4.77 | 19.84 | 303.82 | -52.73 | 65.18 | 0.8270 | -711.6 | -514.7 | |
| 0.00 | 1.28 | 0.00 | 1.12 | 19.68 | 303.64 | -52.92 | 65.42 | 0.8282 | -654.0 | -510.1 | |
| 0.00 | 0.85 | 0.00 | 0.74 | 18.86 | 303.76 | -52.80 | 66.34 | 0.8251 | -614.0 | -479.2 | |
| 0.00 | 1.11 | 0.00 | 0.99 | 19.69 | 302.68 | -53.88 | 65.69 | 0.8367 | -472.0 | -390.8 | |
| 1.70 | 5.11 | 1.51 | 4.53 | 18.84 | 303.04 | -53.52 | 66.58 | 0.8315 | -564.6 | -554.4 | |
| 0.00 | 0.77 | 0.00 | 0.68 | 19.34 | 302.80 | -53.76 | 66.06 | 0.8349 | -565.0 | -476.2 | |
| 0.00 | 1.02 | 0.00 | 0.91 | 19.12 | 302.80 | -53.76 | 66.31 | 0.8343 | -426.0 | -411.8 | |
| 0.00 | 0.94 | 0.00 | 0.88 | 21.70 | 301.33 | -55.23 | 63.76 | 0.8530 | -410.0 | -348.9 | |
| 0.00 | 1.11 | 0.00 | 0.99 | 19.25 | 302.57 | -53.98 | 66.23 | 0.8366 | -428.0 | -384.5 | |
| 0.00 | 2.21 | 0.00 | 1.98 | 18.97 | 302.66 | -53.90 | 66.53 | 0.8352 | -577.0 | -457.9 | |
| 4.43 | 9.28 | 4.08 | 8.55 | 20.27 | 301.84 | -54.71 | 65.26 | 0.8453 | -482.0 | -372.5 | |
| 0.00 | 1.19 | 0.00 | 1.02 | 16.19 | 303.69 | -52.86 | 69.53 | 0.8194 | -550.0 | -447.1 | |
| 0.00 | 0.85 | 0.00 | 0.77 | 19.22 | 302.21 | -54.35 | 66.36 | 0.8397 | -414.0 | -322.9 | |
| 0.00 | 1.79 | 0.00 | 1.64 | 19.83 | 301.75 | -54.81 | 65.79 | 0.8451 | -717.0 | -575.3 | |
| 0.00 | 1.70 | 0.00 | 1.58 | 19.45 | 301.39 | -55.17 | 66.32 | 0.8473 | -465.0 | -287.6 | |
| 0.00 | 5.45 | 0.00 | 5.08 | 19.68 | 301.22 | -55.34 | 66.11 | 0.8492 | -616.0 | -473.9 | |
| 1.19 | 1.70 | 1.19 | 1.70 | 22.40 | 299.41 | -57.15 | 63.51 | 0.8698 | -295.3 | -274.5 | |
| 0.00 | 0.85 | 0.00 | 0.80 | 19.55 | 300.95 | -55.61 | 66.32 | 0.8512 | -265.0 | -232.4 | |
| 0.00 | 1.02 | 0.00 | 1.02 | 22.17 | 299.43 | -57.12 | 63.76 | 0.8691 | -441.0 | -358.9 | |
| 0.00 | 9.45 | 0.00 | 8.96 | 20.06 | 300.62 | -55.94 | 65.82 | 0.8551 | -248.0 | -238.3 | |
| 0.00 | 0.43 | 0.00 | 0.41 | 20.41 | 300.43 | -56.13 | 65.48 | 0.8574 | -6.0 | -63.8 | |
| 0.00 | 1.96 | 0.00 | 1.94 | 21.69 | 299.50 | -57.06 | 64.28 | 0.8676 | -176.0 | -72.2 | |
| 0.00 | 1.02 | 0.00 | 0.97 | 19.65 | 300.67 | -55.88 | 66.28 | 0.8538 | -217.0 | -134.6 | |
| 0.00 | 0.68 | 0.00 | 0.77 | 25.98 | 296.10 | -60.46 | 60.45 | 0.9009 | 470.0 | 443.2 | |
| 0.00 | 1.28 | 0.00 | 1.45 | 25.29 | 295.81 | -60.74 | 61.26 | 0.9015 | 295.0 | 253.2 | |
| 3.15 | 10.47 | 3.23 | 10.63 | 21.96 | 298.25 | -58.31 | 64.30 | 0.8778 | 663.8 | 566.2 | |
| 0.00 | 1.02 | 0.00 | 1.05 | 21.71 | 298.23 | -58.32 | 64.58 | 0.8774 | 473.0 | 449.2 | |
| 0.00 | 1.45 | 0.00 | 1.50 | 22.00 | 297.92 | -58.64 | 64.34 | 0.8803 | 387.0 | 371.5 | |
| 1.28 | 1.53 | 1.26 | 1.51 | 19.86 | 299.18 | -57.38 | 66.42 | 0.8664 | -300.7 | -261.7 | |
| 0.00 | 0.68 | 0.00 | 0.71 | 21.78 | 297.51 | -59.05 | 64.68 | 0.8830 | 411.0 | 374.5 | |
| 0.00 | 0.60 | 0.00 | 0.68 | 24.48 | 295.42 | -61.14 | 62.23 | 0.9026 | 345.0 | 282.1 | |
| 0.00 | 0.68 | 0.00 | 0.77 | 23.86 | 295.45 | -61.10 | 62.89 | 0.9013 | 573.0 | 529.0 | |
| 0.00 | 1.02 | 0.00 | 1.17 | 23.90 | 295.01 | -61.54 | 62.95 | 0.9043 | 370.0 | 309.8 | |
| 1.70 | 2.47 | 1.99 | 2.88 | 23.36 | 294.36 | -62.20 | 63.69 | 0.9078 | 323.0 | 367.7 | |
| 1.02 | 3.06 | 1.21 | 3.62 | 23.30 | 294.06 | -62.50 | 63.82 | 0.9096 | 285.4 | 370.2 | |
| 0.00 | 1.62 | 0.00 | 1.92 | 23.07 | 293.82 | -62.73 | 64.11 | 0.9108 | 244.0 | 173.4 | |
| 0.00 | 1.02 | 0.00 | 1.13 | 20.82 | 295.34 | -61.21 | 66.23 | 0.8970 | 422.0 | 303.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
