SDO HMI 2011-12-14 02:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 76.37 | 437.53 | 39.63 | 226.94 | -18.08 | 352.17 | -1.08 | 176.58 | 0.3000 | 1098.2 | 444.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-12-14 02:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.19 | 0.00 | 0.61 | -14.49 | 357.36 | 4.10 | 196.25 | 0.2488 | 697.0 | 533.3 | |
| 0.00 | 1.02 | 0.00 | 0.53 | -18.45 | 354.64 | 1.39 | 184.32 | 0.3064 | -768.0 | -645.3 | |
| 0.00 | 2.04 | 0.00 | 1.07 | -19.10 | 353.99 | 0.74 | 182.21 | 0.3166 | -877.0 | -703.9 | |
| 55.51 | 403.74 | 28.76 | 209.35 | -17.77 | 352.31 | -0.94 | 176.94 | 0.2946 | 1440.7 | 452.5 | |
| 15.33 | -4.00 | 7.99 | -4.00 | -18.94 | 352.24 | -1.01 | 176.94 | 0.3143 | 1127.6 | 999999 | |
| 5.53 | -4.00 | 2.88 | -4.00 | -18.38 | 351.63 | -1.63 | 174.91 | 0.3057 | 1042.2 | 999999 | |
| 0.00 | 1.70 | 0.00 | 0.89 | -19.41 | 351.40 | -1.86 | 174.54 | 0.3230 | 832.0 | 752.7 | |
| 0.00 | 7.24 | 0.00 | 3.78 | -19.32 | 351.21 | -2.05 | 173.97 | 0.3218 | 747.0 | 749.5 | |
| 0.00 | 5.79 | 0.00 | 3.01 | -18.51 | 351.10 | -2.16 | 173.32 | 0.3087 | 919.0 | 766.5 | |
| 0.00 | 0.85 | 0.00 | 0.44 | -15.74 | 350.70 | -2.56 | 170.58 | 0.2636 | -511.0 | -437.3 | |
| 0.00 | 3.49 | 0.00 | 1.81 | -17.80 | 350.48 | -2.77 | 171.08 | 0.2983 | 703.0 | 623.2 | |
| 0.00 | 1.28 | 0.00 | 0.66 | -17.55 | 350.30 | -2.95 | 170.36 | 0.2947 | 990.0 | 734.1 | |
| 0.00 | 4.17 | 0.00 | 2.15 | -16.26 | 350.26 | -2.99 | 169.39 | 0.2735 | -890.0 | -842.2 | |
| 0.00 | 1.87 | 0.00 | 0.98 | -19.75 | 350.20 | -3.05 | 171.25 | 0.3311 | 964.0 | 722.7 | |
| 0.00 | 1.96 | 0.00 | 1.03 | -20.03 | 350.19 | -3.06 | 171.37 | 0.3357 | 871.0 | 659.1 | |
| 0.00 | 1.19 | 0.00 | 0.63 | -20.19 | 350.16 | -3.09 | 171.35 | 0.3383 | 675.0 | 537.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
