SDO HMI 2011-12-14 07:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 1.19 | 18.81 | 0.67 | 11.01 | -18.46 | 323.41 | -27.11 | 125.26 | 0.5313 | -468.1 | -427.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-12-14 07:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.11 | 0.00 | 0.62 | -19.34 | 329.30 | -21.23 | 133.05 | 0.4695 | -731.0 | -594.2 | |
| 0.00 | 1.19 | 0.00 | 0.66 | -14.29 | 327.42 | -23.11 | 121.68 | 0.4488 | -657.0 | -520.4 | |
| 1.19 | 1.96 | 0.67 | 1.11 | -16.48 | 326.08 | -24.45 | 124.41 | 0.4830 | 868.8 | 805.0 | |
| 0.00 | 1.53 | 0.00 | 0.87 | -16.60 | 325.96 | -24.56 | 124.51 | 0.4854 | 420.0 | 559.4 | |
| 0.00 | 1.87 | 0.00 | 1.12 | -23.10 | 324.14 | -26.38 | 132.99 | 0.5610 | -347.0 | -335.3 | |
| 0.00 | 1.02 | 0.00 | 0.60 | -18.65 | 322.53 | -28.00 | 124.74 | 0.5434 | -836.0 | -654.6 | |
| 0.00 | 5.53 | 0.00 | 3.25 | -17.97 | 322.47 | -28.05 | 123.59 | 0.5392 | -925.0 | -683.8 | |
| 0.00 | 2.13 | 0.00 | 1.26 | -18.43 | 322.18 | -28.35 | 124.08 | 0.5461 | -779.0 | -621.0 | |
| 0.00 | 1.53 | 0.00 | 0.94 | -19.87 | 318.93 | -31.60 | 123.73 | 0.5948 | -663.0 | -500.8 | |
| 0.00 | 0.94 | 0.00 | 0.58 | -20.15 | 318.38 | -32.15 | 123.75 | 0.6030 | -591.0 | -499.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
