SDO HMI 2011-12-14 10:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 13.71 | 77.41 | 10.87 | 62.05 | 20.67 | 300.68 | -48.22 | 62.61 | 0.7866 | -256.1 | -231.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-12-14 10:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.62 | 0.00 | 1.17 | 19.14 | 305.56 | -43.33 | 62.51 | 0.7331 | -520.0 | -454.2 | |
| 0.00 | 1.02 | 0.00 | 0.74 | 18.67 | 305.24 | -43.65 | 63.25 | 0.7346 | -572.0 | -471.4 | |
| 0.00 | 1.11 | 0.00 | 0.81 | 18.58 | 305.10 | -43.79 | 63.43 | 0.7358 | -683.0 | -583.3 | |
| 0.00 | 1.28 | 0.00 | 0.96 | 19.66 | 303.94 | -44.95 | 62.55 | 0.7521 | -754.0 | -627.3 | |
| 1.45 | 1.70 | 1.09 | 1.28 | 19.98 | 303.69 | -45.20 | 62.26 | 0.7558 | -595.4 | -492.7 | |
| 0.00 | 1.02 | 0.00 | 0.75 | 18.21 | 304.26 | -44.63 | 64.25 | 0.7433 | -647.0 | -559.9 | |
| 0.00 | 0.94 | 0.00 | 0.70 | 19.79 | 303.71 | -45.18 | 62.49 | 0.7548 | -696.0 | -570.8 | |
| 0.00 | 3.75 | 0.00 | 2.79 | 18.97 | 303.92 | -44.97 | 63.43 | 0.7497 | -749.0 | -630.5 | |
| 0.00 | 1.02 | 0.00 | 0.75 | 17.97 | 304.12 | -44.77 | 64.63 | 0.7438 | -712.0 | -629.3 | |
| 0.00 | 0.94 | 0.00 | 0.76 | 24.07 | 301.63 | -47.26 | 58.17 | 0.7916 | -324.0 | -366.2 | |
| 4.43 | 6.04 | 3.33 | 4.54 | 18.97 | 303.47 | -45.42 | 63.61 | 0.7543 | -685.8 | -635.2 | |
| 0.00 | 2.47 | 0.00 | 1.87 | 19.29 | 303.22 | -45.67 | 63.31 | 0.7580 | -528.0 | -480.8 | |
| 0.00 | 0.94 | 0.00 | 0.71 | 19.14 | 303.05 | -45.84 | 63.57 | 0.7591 | -587.0 | -514.4 | |
| 0.00 | 1.19 | 0.00 | 0.91 | 19.45 | 302.89 | -46.00 | 63.24 | 0.7619 | -504.0 | -356.4 | |
| 0.00 | 0.51 | 0.00 | 0.40 | 21.55 | 301.92 | -46.97 | 61.05 | 0.7792 | -530.0 | -476.3 | |
| 0.00 | 1.36 | 0.00 | 1.16 | 25.76 | 299.46 | -49.43 | 57.10 | 0.8171 | -510.0 | -465.5 | |
| 0.00 | 0.94 | 0.00 | 0.71 | 18.45 | 302.67 | -46.23 | 64.58 | 0.7607 | -625.0 | -516.5 | |
| 0.00 | 0.26 | 0.00 | 0.20 | 19.11 | 302.25 | -46.65 | 63.92 | 0.7673 | -555.0 | -523.7 | |
| 0.00 | 2.89 | 0.00 | 2.27 | 20.47 | 301.67 | -47.22 | 62.46 | 0.7778 | -480.0 | -397.7 | |
| 0.43 | 4.00 | 0.33 | 3.13 | 20.19 | 301.74 | -47.15 | 62.79 | 0.7761 | -665.0 | -605.3 | |
| 0.00 | 2.30 | 0.00 | 1.79 | 19.81 | 301.84 | -47.05 | 63.21 | 0.7737 | -618.0 | -483.4 | |
| 0.00 | 3.32 | 0.00 | 2.54 | 18.52 | 302.33 | -46.57 | 64.63 | 0.7644 | -563.0 | -471.9 | |
| 0.00 | 1.87 | 0.00 | 1.44 | 18.83 | 302.03 | -46.86 | 64.35 | 0.7685 | -563.0 | -485.2 | |
| 3.23 | 7.58 | 2.54 | 5.94 | 19.59 | 301.42 | -47.47 | 63.64 | 0.7772 | -617.9 | -510.9 | |
| 0.00 | 0.94 | 0.00 | 0.71 | 16.43 | 302.39 | -46.50 | 67.24 | 0.7569 | -513.0 | -390.7 | |
| 0.00 | 1.87 | 0.00 | 1.41 | 16.28 | 302.35 | -46.54 | 67.45 | 0.7568 | -486.0 | -457.3 | |
| 0.00 | 1.28 | 0.00 | 1.02 | 20.01 | 300.78 | -48.11 | 63.37 | 0.7848 | -486.0 | -451.9 | |
| 0.00 | 0.94 | 0.00 | 0.75 | 20.20 | 300.61 | -48.28 | 63.20 | 0.7871 | -327.0 | -301.9 | |
| 0.00 | 0.94 | 0.00 | 0.75 | 20.11 | 300.50 | -48.39 | 63.35 | 0.7878 | -304.0 | -221.1 | |
| 0.00 | 0.94 | 0.00 | 0.78 | 22.38 | 299.14 | -49.75 | 61.14 | 0.8081 | -537.0 | -393.7 | |
| 0.00 | 1.11 | 0.00 | 0.94 | 22.52 | 298.42 | -50.47 | 61.24 | 0.8150 | -396.0 | -316.5 | |
| 0.00 | 1.19 | 0.00 | 1.06 | 24.32 | 296.92 | -51.97 | 59.70 | 0.8335 | 594.0 | 575.2 | |
| 0.00 | 1.11 | 0.00 | 1.04 | 26.57 | 295.45 | -53.44 | 57.67 | 0.8523 | 480.0 | 377.6 | |
| 4.17 | 5.36 | 3.58 | 4.60 | 22.05 | 297.85 | -51.05 | 61.99 | 0.8186 | 695.8 | 597.9 | |
| 0.00 | 1.87 | 0.00 | 1.72 | 25.31 | 295.89 | -53.00 | 58.93 | 0.8450 | 552.0 | 521.8 | |
| 0.00 | 1.45 | 0.00 | 1.27 | 22.86 | 297.06 | -51.83 | 61.32 | 0.8279 | 500.0 | 490.5 | |
| 0.00 | 0.94 | 0.00 | 0.84 | 23.35 | 296.21 | -52.68 | 61.04 | 0.8367 | 495.0 | 436.3 | |
| 0.00 | 1.36 | 0.00 | 1.20 | 22.19 | 296.79 | -52.10 | 62.19 | 0.8283 | 486.0 | 436.1 | |
| 0.00 | 0.85 | 0.00 | 0.78 | 23.62 | 295.40 | -53.49 | 61.00 | 0.8441 | 483.0 | 452.2 | |
| 0.00 | 1.19 | 0.00 | 1.11 | 24.11 | 295.05 | -53.84 | 60.56 | 0.8483 | 364.0 | 305.6 | |
| 0.00 | 1.45 | 0.00 | 1.33 | 23.49 | 295.37 | -53.52 | 61.16 | 0.8440 | 616.0 | 570.8 | |
| 0.00 | 2.55 | 0.00 | 2.42 | 23.22 | 293.99 | -54.90 | 61.90 | 0.8545 | 577.0 | 445.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
