SDO HMI 2011-12-14 14:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 11.58 | 75.29 | 8.59 | 58.75 | 21.24 | 300.14 | -46.55 | 61.25 | 0.7721 | -207.7 | -116.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-12-14 14:58:55 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.28 | 0.00 | 0.81 | 18.76 | 312.45 | -34.25 | 58.05 | 0.6304 | 616.0 | 544.9 | |
| 0.00 | 1.19 | 0.00 | 0.84 | 18.83 | 305.30 | -41.39 | 62.02 | 0.7111 | -681.0 | -573.1 | |
| 0.00 | 1.11 | 0.00 | 0.78 | 18.58 | 305.25 | -41.44 | 62.37 | 0.7105 | -663.0 | -615.1 | |
| 0.00 | 1.02 | 0.00 | 0.72 | 18.24 | 304.60 | -42.10 | 63.12 | 0.7162 | -648.0 | -542.0 | |
| 0.00 | 0.68 | 0.00 | 0.48 | 18.77 | 304.39 | -42.30 | 62.51 | 0.7207 | -609.0 | -568.9 | |
| 0.00 | 1.11 | 0.00 | 0.80 | 19.66 | 303.98 | -42.71 | 61.56 | 0.7288 | -696.0 | -559.0 | |
| 1.96 | 2.30 | 1.40 | 1.64 | 18.90 | 304.14 | -42.55 | 62.46 | 0.7239 | -656.5 | -461.0 | |
| 1.11 | 1.79 | 0.80 | 1.30 | 19.94 | 303.67 | -43.02 | 61.34 | 0.7333 | -639.5 | -494.1 | |
| 0.00 | 1.28 | 0.00 | 0.91 | 18.02 | 304.24 | -42.45 | 63.56 | 0.7192 | -649.0 | -535.5 | |
| 0.00 | 0.34 | 0.00 | 0.24 | 18.09 | 304.22 | -42.47 | 63.49 | 0.7196 | -776.0 | -725.8 | |
| 0.00 | 0.34 | 0.00 | 0.27 | 25.24 | 301.15 | -45.55 | 56.02 | 0.7810 | -491.0 | -466.0 | |
| 3.15 | 6.72 | 2.27 | 4.86 | 18.97 | 303.61 | -43.09 | 62.62 | 0.7299 | -728.9 | -652.2 | |
| 0.00 | 0.94 | 0.00 | 0.68 | 19.35 | 303.31 | -43.38 | 62.26 | 0.7346 | -593.0 | -505.9 | |
| 0.00 | 0.94 | 0.00 | 0.68 | 19.13 | 303.13 | -43.57 | 62.62 | 0.7357 | -571.0 | -499.2 | |
| 0.00 | 1.11 | 0.00 | 0.86 | 23.45 | 301.42 | -45.28 | 58.03 | 0.7707 | -564.0 | -414.2 | |
| 0.00 | 1.28 | 0.00 | 0.96 | 21.39 | 301.87 | -44.83 | 60.34 | 0.7577 | -493.0 | -378.0 | |
| 0.00 | 0.77 | 0.00 | 0.62 | 24.90 | 300.00 | -46.70 | 56.95 | 0.7899 | -406.0 | -332.9 | |
| 0.00 | 1.28 | 0.00 | 0.96 | 20.57 | 301.69 | -45.00 | 61.44 | 0.7562 | -470.0 | -389.3 | |
| 0.00 | 2.72 | 0.00 | 2.24 | 25.76 | 299.31 | -47.38 | 56.24 | 0.7995 | -476.0 | -400.0 | |
| 0.00 | 0.68 | 0.00 | 0.51 | 20.41 | 301.71 | -44.99 | 61.63 | 0.7554 | -545.0 | -421.2 | |
| 0.00 | 3.66 | 0.00 | 2.75 | 20.15 | 301.76 | -44.94 | 61.92 | 0.7539 | -669.0 | -601.0 | |
| 0.00 | 1.19 | 0.00 | 0.88 | 19.14 | 302.07 | -44.62 | 63.06 | 0.7467 | -496.0 | -465.3 | |
| 0.00 | 1.87 | 0.00 | 1.40 | 19.87 | 301.77 | -44.92 | 62.27 | 0.7526 | -737.0 | -619.5 | |
| 0.00 | 1.28 | 0.00 | 0.94 | 18.80 | 302.10 | -44.59 | 63.49 | 0.7451 | -641.0 | -534.8 | |
| 2.21 | 5.11 | 1.66 | 3.84 | 19.53 | 301.54 | -45.16 | 62.80 | 0.7537 | -603.7 | -437.3 | |
| 0.00 | 2.47 | 0.00 | 1.79 | 16.40 | 302.46 | -44.23 | 66.44 | 0.7324 | -554.0 | -503.2 | |
| 1.96 | -25.00 | 1.48 | -25.00 | 19.69 | 301.35 | -45.35 | 62.68 | 0.7562 | -498.1 | 999999 | |
| 0.00 | 1.19 | 0.00 | 0.90 | 19.59 | 301.16 | -45.54 | 62.87 | 0.7578 | -414.0 | -300.1 | |
| 0.00 | 3.49 | 0.00 | 2.66 | 19.91 | 300.81 | -45.88 | 62.62 | 0.7625 | -567.0 | -341.7 | |
| 0.00 | 1.28 | 0.00 | 0.98 | 20.17 | 300.54 | -46.16 | 62.41 | 0.7662 | -346.0 | -248.3 | |
| 0.00 | 1.45 | 0.00 | 1.18 | 22.58 | 298.38 | -48.32 | 60.35 | 0.7957 | -482.0 | -349.1 | |
| 0.00 | 1.53 | 0.00 | 1.25 | 22.33 | 298.31 | -48.39 | 60.68 | 0.7955 | -421.0 | -273.8 | |
| 0.00 | 1.11 | 0.00 | 0.99 | 26.86 | 295.74 | -50.95 | 56.44 | 0.8336 | 523.0 | 482.3 | |
| 1.19 | 3.57 | 0.98 | 2.93 | 22.14 | 297.91 | -48.79 | 61.06 | 0.7985 | 784.4 | 657.8 | |
| 0.00 | 1.36 | 0.00 | 1.16 | 24.35 | 296.80 | -49.90 | 58.90 | 0.8161 | 639.0 | 597.1 | |
| 0.00 | 0.85 | 0.00 | 0.76 | 26.54 | 295.42 | -51.28 | 56.93 | 0.8351 | 419.0 | 351.7 | |
| 0.00 | 1.11 | 0.00 | 0.97 | 25.47 | 295.86 | -50.84 | 57.97 | 0.8279 | 603.0 | 503.8 | |
| 0.00 | 1.70 | 0.00 | 1.42 | 22.63 | 297.19 | -49.51 | 60.76 | 0.8068 | 488.0 | 571.2 | |
| 0.00 | 1.62 | 0.00 | 1.36 | 22.86 | 296.87 | -49.82 | 60.60 | 0.8104 | 584.0 | 459.3 | |
| 0.00 | 0.94 | 0.00 | 0.79 | 22.25 | 296.78 | -49.92 | 61.35 | 0.8092 | 469.0 | 437.8 | |
| 0.00 | 1.11 | 0.00 | 0.98 | 24.01 | 295.08 | -51.61 | 59.92 | 0.8297 | 468.0 | 361.4 | |
| 0.00 | 0.43 | 0.00 | 0.37 | 23.62 | 295.20 | -51.50 | 60.33 | 0.8275 | 306.0 | 319.0 | |
| 0.00 | 1.62 | 0.00 | 1.42 | 23.36 | 295.13 | -51.56 | 60.65 | 0.8272 | 598.0 | 513.9 | |
| 0.00 | 1.02 | 0.00 | 0.88 | 22.71 | 295.48 | -51.22 | 61.27 | 0.8222 | 720.0 | 596.8 | |
| 0.00 | 0.85 | 0.00 | 0.80 | 26.30 | 293.18 | -53.51 | 58.00 | 0.8520 | 260.0 | 282.7 | |
| 0.00 | 1.02 | 0.00 | 0.89 | 22.49 | 295.24 | -51.46 | 61.62 | 0.8237 | 556.0 | 449.2 | |
| 0.00 | 2.30 | 0.00 | 2.07 | 23.22 | 293.95 | -52.75 | 61.22 | 0.8368 | 593.0 | 404.1 | |
| 0.00 | 1.28 | 0.00 | 1.23 | 24.90 | 291.64 | -55.06 | 60.06 | 0.8601 | 366.0 | 271.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
